Elo TouchSystems Paypoint

Paypoint POS Computers


PayPoint for Windows integrates with all your back-office applications, leveraging the management and security of Microsoft Windows. Designed for ease of serviceability, PayPoint provides easy access to memory and storage compartments. Performance for point of sale applications is powered by an Intel® Celeron® quad-core processor.

A clean, modern, fully integrated solution for today’s business. PayPoint for Windows (includes cash drawer, printer, MSR, bar code scanner, customer facing display), RJ45 to DB9 cable for external printer and other devices, Ethernet cable, Power cable, 2 receipt paper rolls, 2 cash drawer keys, Quick Install Guide

Paypoint Powered by Android™ 7.1 (Nougat), the upgraded PayPoint for Android point of sale solution offers the same sleek and elegant design now delivering 4x the speed with the Qualcomm® Snapdragon™ octa-core processor, 3GB of RAM and 32GB of storage. The retail hardened all-in-one mPOS solution brings simplicity and modern style to the point of sale with peripherals built in and reliability backed by a three-year warranty.

Don't forget the paper! Buy a case of 2" thermal receipt paper here!
Product Specifications
Color White
Processor (Windows) Intel 2GHz Celeron Quad-Core J1900; 2MB L2 Cache; fanless
Processor (Android) Qualcomm Snapdragon 2.0GHz Octa-Core
Memory (RAM) (Android) 3GB
Memory (RAM) (Windows) 4GB 1600MHz DDR3L SO-DIMM on 1 slot (upgradeable to 8GB)
Storage (Windows) 128GB SSD
Storage (Android) 32GB NOTE: GB equals one billion bytes when referring to storage capacity. Accessible capacity may be less
Display 13.3” diagonal, Active matrix TFT LCD (LED), 16x9
Screen 11.55” x 6.50” (293.47mm x 165.08mm) (W x H)
Resolution Full HD 1920 x 1080
Touch Technology IntelliTouch Pro zero-bezel 10-touch projected capacitive (PCAP)
Brightness LCD panel: 330 nits; Intellitouch Pro: 300 nits
Viewing Angle Horizontal: 170°
Vertical: 170°
Contrast Ratio 700:1
Connectivity Wi-Fi 802.11ac & Bluetooth 4.0
Ports Serial: 1 x native serial port (RJ-45) with DB9 adapter cable included
USB Ports: 1 x USB 3.0 (side) and 2 x USB 2.0 (bottom)
Ethernet Ports: 1 x LAN RJ45 (Gigabit)
Cash Drawer Specs 4 bill trays, 5 coin compartments, 1 check slot, mechanical locking key
Printer Specs Thermal 2 1/4” (58mm); accepts 2-inch (50mm) thermal paper roll
Barcode Scanner 1D Scanner
Magnetic Stripe Reader 3-track encryptable - encryption key and verifiation of encryption is customer responsibility
Customer Facing Accent 2 line, 16 character display
Operating System Options: Windows Embedded POSReady 7
Windows Embedded Enterprise 7
No Operating System
Dimensions 13.5” x 15.7” (343mm x 399mm)
Weight 14.4 lbs (6.51kg) unpackaged
20.0 lbs (9.07kg) packaged
Shipping Dimensions 18.9” x 11.2” x 16.5” (480mm x 285mm x 420mm)
Operating Temperature 32°F to 95°F (0°C to 35°C)
Storage Temperature -4°F to 140°F (-20°C to 60°C)
Humidity Operating: 10% to 90%
Storage: 0% to 95%
Power Supply Internal AC input voltage: 100-240VAC; Input frequency: 50-60Hz; 75W max.
MTBF 50,000 hours demonstrated
Warranty 3 Years

Elo TouchSystems Paypoint Reviews

POSGuys Rating: Not Rated

Customer Reviews

Add a customer product review

Recommended Models

Elo Paypoint All In One Touch POS System, White with Integrated Receipt Printer and Cash Drawer, Barcode Scanner, 13.3" LED LCD Fanless Celeron Quad Core J1900, P-CAP, Zero-Bezel, Windows 7 Pro OS
$1,645.00
  • operating system: Windows 7 Pro
  • processor: Celeron Quad Core J1900
Elo Paypoint All In One Touch POS System, White with Integrated Receipt Printer and Cash Drawer, Barcode Scanner, 13.3" LED LCD Fanless Celeron Quad Core J1900, P-CAP, Zero-Bezel, POS Ready 7
$1,600.00
  • operating system: POSReady 7
  • processor: Celeron Quad Core J1900

Additional Models

Elo PayPoint for Windows, 13.3-inch, NA, Celeron J1900, 4GB RAM, 128GB SSD, No OS, Projected Capacitive 10-touch, Clear, Zero-bezel, cash drawer, barcode scanner, receipt printer, customer facing display, White
$1,447.58
  • operating system: No OS
  • processor: Celeron Quad Core J1900
Elo PayPoint Plus, Android 7.1, 15.6-inch, projective capacitive, 3GB RAM, 32GB SSD, 3-inch printer, 2D barcode scanner, 4x8 cash drawer, white, worldwide
$1,572.64
  • operating system: Android 7.1
  • processor: ARM A9
Elo PayPoint, Android 7.1, 13.3-inch, Projective Capacitive, 3GB RAM, 32GB SSD, 2-inch receipt printer, 1D barcode scanner, cash drawer, White, Worldwide
$1,183.58
  • operating system: Android 7.1
  • processor: ARM A9
Elo PayPoint Plus, Android 7.1, 15.6-inch, projective capacitive, 3GB RAM, 32GB SSD, 3-inch printer, 2D barcode scanner, 5x6 cash drawer, CFD, white, North America/China
$1,572.64
  • operating system: Android 7.1
  • processor: ARM A9
Elo PayPoint, Android 7.1, 13.3-inch, Projective Capacitive, 3GB RAM, 32GB SSD, 2-inch receipt printer, 1D barcode scanner, cash drawer, CFD, White, North America/China
$1,183.58
  • operating system: Android 7.1
  • processor: ARM A9
Elo PayPoint for Android, 13.3-inch, NA, ARM A9 2GHz,1GB RAM, 16GB SSD, Android OS, Projected Capacitive Dual-touch, Clear, Zero-bezel, cash drawer, barcode scanner, receipt printer, customer facing display, White
$1,215.16
  • operating system: Android 7.1
  • processor: ARM A9
