TSC TDP-225
The pictures shown are general images for product TDP-225 and may not be applicable to all part numbers
TDP-225 Barcode Printers
The TSC TDP-225 barcode printer is the ideal choice for retailers and health care providers alike. The TDP-225's unique design allows it to load rolls up to 5" in diameter, excellent for wristband printing. A microSD expansion slot allows for up to 4 GB of extended memory, allowing the TDP-225 to print large print jobs with no degradation in performance. At up to 5 inches per second, the print speed of the TDP-225 is snappy enough to keep most low to medium volume labeling operations running smoothly.
Features
- TSPL-EZ, ZPL, EPL printing languages supported
- MicroSD Expansion Slot allows for up to 4 GB additional memory
- Optional front LCD display
- Gap and black mark media sensors
- Driver support for Windows XP Home, Pro, Vista, and 7
- Compatible with Zebra label media
Product Specifications | |
---|---|
Interface | USB, serial RS232, Internal Ethernet |
Print Method | Direct thermal |
Print Speed | 2, 3, 4, 5 ips selectable |
Print Resolution | 203 dpi |
Maximum Print Area | Width: 2.13 in (54 mm) Length: 90 in (2,286 mm) |
Paper Dimensions | Width: 0.59 to 2.36 in (15 to 60 mm) |
Resident Fonts | 8 alpha-numeric bitmap fonts, one monotype image CG triumvirate bold condensed scalable font |
Barcodes Supported | Linear Barcodes: Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2 (5) digits add-on, MSI, PLESSEY, POSTNET, China POST, RSS-14, Code 11 2D Barcodes: PDF-417, Maxicode, DataMatrix, QR code, Aztec |
Memory | 4 MB Flash, 8 MB SDRAM, MicroSD card slot for memory expansion up to 4 GB |
Printer Languages | TSPL-EZ™ |
Two Color Printing Capabilities | No |
Auto Cutter | Optional - guillotine cutter full cut or partial cut |
Peeler / Presenter | Optional - peel off module assembly |
Internal Rewind | No |
LCD Display | Optional - 128 x 64 px graphic type display with back light |
Dimensions | 8.23L 4.29W x 6.73H (209 x 109 x 171 mm) |
Wall Mountable | No |
Operating Temperature | 41°F - 104°F (5°C - 40°C) |
Downloads |
---|
Data Sheet |
TSC Diagnostic Tool |
Manual (English) |
Manual (Español) |
Quick Start Guide (English) |
Quick Start Guide (Español) |
Seagull Windows Driver |
Windows Driver |
