Brother TD-4

The pictures shown are general images for product TD-4 and may not be applicable to all part numbers

Buy it now View Accessories

POSGuys Rating:Not Rated

Lifetime Support

2 Year Warranty

15 Day Return Period

Free Shipping

TD-4 Features

4.25 inch

DT & TT

Description
Specs
Review
Downloads

TD-4 Barcode Printers

Print performance, meet affordability.

With 4-inch Desktop Direct Thermal Printers from Brother, you have the capabilities you need to move inventory faster, track it better, and minimize the cost of doing it all.

These precision-built barcode label printers deliver the right levels of performance, quality, and integration at an exceptional value. From inventory and shipping to barcode and shelf labeling – now you can easily and affordably produce the labels you need, with the reliability and support that only Brother delivers.

Expect a complete set of connectivity options, superior software compatibility, fast printing, and high resolutions. It’s powerful desktop printing that doesn’t come at a price.

Key Features - Brother TD-4

Simplicity
Help cut costs upfront and improve ROI with the most affordable desktop direct thermal print solutions available.
Affordability
Standardize asset and facility management and traceability labeling across multiple locations.
Quality
203dpi and 300dpi models print clean, crisp barcodes, fonts, logos, and more.
Compatibility
Integrate with WMS systems, manufacturing platforms, and other software solutions.
Reliability
Backed by an industry-leading Two year Premier Limited Warranty, which even includes the printhead.
Performance
Help boost productivity with print speeds up to 8 inches per second.

Industry Applications

Easy to operate and maintain, Brother four-inch desktop direct thermal label printer produces high-quality shipping and barcode labels.

Warehouse

Barcodes
Item marking
License plates

Manufacturing

Parts / product labels
Storage labels

Transportation & Logistics

Shipping labels
Product ID labels
Pallet labels
Parcel and post labels

Retail

Product labels
Inventory labels
Barcodes

BOX CONTENTS - Direct Thermal Model

Printer
AC Adapter
Power Cord
Documents

BOX CONTENTS - Thermal Transfer Model

Printer
AC Adapter
Power Cord
USB Cable
Ribbon Take-Up 1” Core
Ribbon Spindle (2 pieces)
Documents

Product Specifications
Dimensions (W x H x L)	Direct Thermal 7.1in (180mm) x 6.1in (155mm) x 8.8in (224mm) Thermal Transfer TD-4420TN & TD-4520TN: 8.03” (204mm) x 6.46” (164mm) x 11.02” (280mm) TD-4650TNWB & TD-4750TNWB: 8.62” (219mm) x 7.52” (191mm) x 11.2” (284mm)
Power Specifications	Direct Thermal External AC Adapter (Input: 100 - 240VAC 50/60Hz 2.0A, Output: 24VDC 5A) Thermal Transfer TD-4420TN & TD-4520TN: External AC Adapter (Input: 100 - 240VAC 50/60Hz 1.5A, Output: 24VDC 2.5A) TD-4650TNWB & TD-4750TNWB: External AC Adapter (Input: 100 - 240VAC 50/60Hz 2.0A, Output: 24VDC 3.75A)
Printer Memory	Direct Thermal Printer Memory 64MB Flash, 256MB SDRAM Thermal Transfer TD-4420TN & TD-4520TN: 128MB Flash, 64 SDRAM TD-4650TNWB & TD-4750TNWB: 128MB Flash, 128 SDRAM
Control Panel	Direct Thermal 7 Keys / 3 LEDs, LCD TD-4550DNWB: Standard (Coin Cell Battery Optional) Thermal Transfer TD-4420TN & TD-4520TN: 1 Key / 1 LED TD-4650TNWB & TD-4750TNWB: 6 Keys / 1 LED (3 Color), 3.5” Color LCD
Label Designer	Direct Thermal P-Touch Editor to design labels and connect to databases. Thermal Transfer BarTender - UltraLite label design software
Operating Systems	Windows, Linux
SDK Support	Direct Thermal TD-4210D: Windows b-PAC TD-4410D: Windows b-PAC, AndroidTM 4.0.3 or Higher TD-4420DN, TD-4520DN TD-4550DNWB: Windows b-PAC, Android 4.0.3 or Higher, iOS® 11 or Higher Thermal Transfer TD-4420TN & TD-4520TN: Windows Server 2016/2012R2/2012/2008R2/2008, Windows 10/8/7 TD-4650TNWB & TD-4750TNWB: Windows Server 2019/2016/2012R2/2012/2008R2/2008 Windows 10/8/7, Windows Vista, Android v5 or Higher, iOS v9 or Higher
Device Management	BRAdmin Professional 4 for Select Models: TD-4420DN TD-4520DN TD-4550DNWB
Printer Languages	Direct Thermal ZPL II, EPL, DPL, CPCL, Raster Graphics, Text (Template), ESC/P TD-4550DNWB Comes with AirPrint Thermal Transfer FBPL, ZPLII®, EPL2™, DPL
Temperature/Humidity	Direct Thermal Operating: 32°F - 104°F (0°C - 40°C) / 20% - 85% Storage: -4°F - 140°F (-20°C - 60°C) / 5% - 90% Thermal Transfer Operating: 41°F - 104°F (5°C - 40°C) / 25% - 85% Storage: -40°F - 140°F (-40°C - 60°C) / 10% - 90%
Label Peeler	Optional
Automatic Cutter	Optional
Resident Barcodes	Direct Thermal Linear: Code39, Code93, Code128, ITF, UPC-A/E, EAN8/13, GS1-128 (UCC/EAN-128), GS1 DataBar (RSS), MSI/Plessey, Industrial 2/5, Codabar (NW-7), POSTNET 2D: PDF417/MicroPDF417, Data Matrix, Maxicode, QR Code/Micro QR Code, Aztec Thermal Transfer Linear: Code39, Code93, Code128, ITF, UPC-A/E, EAN8/13, GS1-128 (UCC/ EAN-128), GS1 DataBar (RSS), MSI/Plessey, Industrial 2/5, Codabar (NW-7), ITF14, EAN14, Code 49, POSTNET, LOGMARS, Code11, TELEPEN, PLANET, Deutsche Post Identcode, Deutsche Post Leitcode, China Post 2D: PDF417/MicroPDF417, Data Matrix, Maxicode, QR Code, Aztec
Printer Sensors	Direct Thermal Top Cover, Transmissive (Gap), Full Width Moveable Reflective (Black Mark), Peeler (Option) Thermal Transfer Printer Sensors Transmissive (Gap), Full Width Moveable Reflective (Black Mark), Option: Peeler
Media Type	Direct Thermal Brother RD Roll or Fan-Fold, Die Cut or Continuous Label, Continuous Receipt, Tag and Wristband Thermal Transfer Roll or Fan-Fold / Die Cut or Continuous / Label, Receipt, Tag and Wristband
Media Roll Size	Direct Thermal Up to 5in (127mm) Outer Diameter \| Core size from 0.5in to 1.5in Inside Diameter Thermal Transfer 5.00” (127mm) Outer Diameter, 1” (25.4mm) or 1.5” (38.1mm) Core Inside Diameter
Media Loading	Direct Thermal Drop-In Spindle-Less Design \| Rear Feed (External Roll or Fanfold) Thermal Transfer Drop-In Spindle-Less Design, Rear Feed (External Roll and Fanfold)
Media Specifications	Direct Thermal Width: 0.8in - 4.7in (19mm - 118mm) \| Thickness: 2mil - 11mil (0.06mm - 0.28mm) Length: 0.3in - 118.1in (6.4mm - 3000.0mm) Thermal Transfer Width: 0.79” - 4.41” (20mm - 112mm), Thickness: 2.36mil – 7.48mil (0.06mm - 0.19mm), Length (203dpi): 0.2” – 1,000” (5mm – 25,400mm), Length (300dpi): 0.2” – 450” (5mm – 11,430mm), Length (Peeler/Cutter): 1” – 6” (25.4mm – 152.4mm)
Ribbon Specs	Ribbon Types: Wax, Semi (Wax/Resin), Resin Ribbon Length: 984’ (300m) / 2.64” (67mm) OD on 1” Core, 361’ (110m) / 1.57” (40mm) OD on 0.5” Core Ribbon Width: 4.33” (110mm) – 1.57” (40mm), [Widths < 4.33” (110mm) Requires Included Ribbon Spindle] Ribbon Take Up Core: 4.33” (110mm) / 1” or 0.5” Core w/ 2 Notches, [1” Core w/o Notches Requires Included Ribbon Spindle]
Standard Interfaces	Direct Thermal TD-4210D & TD-4410D: USB 2.0, RS232C Serial TD-4420DN: Ethernet LAN (10/100Base-TX), USB 2.0, RS232C Serial TD-4520DN: Ethernet LAN (10/100Base-TX), USB 2.0, Host USB, RS232C Serial TD-4550DNW: Wi-Fi® WLAN (5GHz 802.11a/n and 2.4GHz 802.11b/g/n Infrastructure, 802.11g/n Wireless Direct), Bluetooth Version 4.2 BLE/MFi Thermal Transfer TD-4420TN & TD-4520TN: Ethernet LAN (10/100Base-TX), USB 2.0, Host-USB, RS232C Serial TD-4650TNWB & TD-4750TNWB: Wi-Fi® WLAN (5GHz 802.11a/n and 2.4GHz 802.11b/g/n Infrastructure), Ethernet LAN (10/100Base-TX)
Security Protocols	Direct Thermal TD-4210D & TD-4410D: None TD-4420DN: LAN: 802.1x (EAP-FAST, PEAP, EAP-TLS, EAPTTLS, EAP-MD5) TD-4520DN: LAN: 802.1x (EAP-FAST, PEAP, EAP-TLS, EAP-TTLS, EAP-MD5) TD-4550DNW: WLAN: 802.1x (EAPFAST, PEAP, EAP-TLS, EAP-TTLS) Thermal Transfer WLAN: 802.1x (EAP-FAST, PEAPv0, EAP-TLS, EAP-TTLS, LEAP)
Wireless Security	Direct Thermal TD-4210D, TD-4410D, TD-4520DN: None TD-4550DNW: Infrastructure: WEP 64/128bit, WPA/WPA2-PSK (TKIP/AES) Wireless Direct: WPA2-PSK (AES) Thermal Transfer Infrastructure: WEP 64/128bit, WPA/WPA2-PSK (TKIP/AES)
Bluetooth Profiles	Direct Thermal TD-4210D, TD-4410D, TD-4520DN: None TD-4550DNW: Serial Port (SPP), Object Push (OPP), Hardcopy Replacement (HCRP), Generic Attribute (GATT) Low Energy Thermal Transfer Serial Port (SPP), GATT
Warranty	2-Year Premier Limited Warranty (includes printhead)

Brother TD-4 Reviews

POSGuys Rating: Not Rated

Customer Reviews

Downloads
TD-4 Direct Thermal Spec Sheet
TD-4 Thermal Transfer Spec Sheet
