Honeywell PC45

PC45  Product Image

The pictures shown are general images for product PC45 and may not be applicable to all part numbers

PC45 Barcode Printers


This product replaces the older Honeywell PC23d.

The next generation of desktop printers brings powerful performance, reliable connectivity, and easy integration in a compact design to tackle rapidly changing everyday work environments.

The PC45 offers a large touch screen, enterprise-level ruggedness, and multiple new design accessories to support various needs. The PC45 is designed for businesses that invest in solutions and want a durable, stable, secure platform to implement them.

Honeywell Printer Edge™ platform provides a centralized management system for your printer network. Allowing real-time visibility, automated software updates, and enhanced security. This efficient and cost-effective solution for businesses looking to optimize printer operations, Honeywell Printer Edge streamlines workflows and helps reduce downtime, making it easier for you to manage costs.

Get connected and stay connected with Wi-Fi 5 and Bluetooth 5.1 LE for continuous productivity. Benefit from WL AN and optional WWAN connectivity for fast data capture allowing for accelerated deployments. With optional low media and low ribbon enabled sensor and RFID, take the guesswork out printer maintenance to avoid unnecessary operational down time.

Whether on a local server or utilizing the Cloud, the PC45 supports variable network protocols and multiple print languages allowing for easy integration and a seamless transition. Smart Parse technology from Honeywell gives the ability to resize objects, barcodes, or font type without any need to get in on the system backend. Honeywell Operational Intelligence takes it one step further providing remote management capabilities for real-time diagnostics and output performance tracking.

Placeholder image
Looking for Compatible Labels or Ribbon?

We offer a selection of labels and ribbon to meet any need. Having trouble finding the label you need? Give our Label Selector Tool a try or give us a call! We have people ready to help.

Product Specifications
Dimensions (L x W x H) 168 mm L x 181.3 mm W x 215.6 H (6.6 in L x 7.1 in W x 8.5 in H)
Weight 1.8 kg (4 lbs)
Operating Temperature 0°C to 45°C (32°F to 113°F)
Max Print Speed
  • At 203 dpi: 2ips up to 8ips
  • At 300 dpi: 2ips up to 6ips
  • Max Print Width
  • 203 dpi: 108 mm (4.25 in)
  • 300 dpi: 106 mm (4.12 in)
  • Media Width 118mm (4.65 in)
    Max Media Diameter 127 mm (5 in) O.D
    Media Core Size 12.7 mm (0.5 in), 25.4 mm (1 in), 38.1 mm (1.5 in)
    Media Sensors Gap, notch, black mark, continuous
    Languages Support Fingerprint (FP), Direct Protocol (DP), Intermec Printer Language (IPL), ZSim2 (ZPL-II), DPL, XML-enabled for SAP AII and Oracle WMS, PDF, C#
    Warranty Two-year warranty; additional service packages available through Honeywell Repair Services

    Honeywell PC45 Reviews

    POSGuys Rating: Not Rated

    Customer Reviews

    Recommended Models

    PC45 Barcode Printer. Direct Thermal. 203 DPI. USB & Ethernet Interface. Full Touch 3.5-inch LCD. Includes Power Supply & Power Cord.
    Print Type: Direct Thermal
    DPI:203
    Interface:USB & Ethernet
    PC45 Barcode Printer. Direct Thermal. 203 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. Full Touch 3.5-inch LCD. Includes Power Supply.
    Print Type: Direct Thermal
    DPI:203
    Interface:USB, Ethernet, Bluetooth, and WiFi
    PC45 Barcode Printer. Thermal Transfer. 203 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. Full Touch 3.5-inch LCD. Includes Power Supply & Power Cord.
    $1019.37 Add to Cart
    DPI:203
    Print Type:Thermal Transfer
    Interface:USB, Ethernet, Bluetooth, and WiFi
    PC45 Barcode Printer. Thermal Transfer. 203 DPI. USB & Ethernet Interface. Full Touch 3.5-inch LCD. Includes Power Supply & Power Cord.
    DPI:203
    Print Type:Thermal Transfer
    Interface:USB & Ethernet

    Additional Models

    PC45 Barcode Printer. Direct Thermal. 203 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. Healthcare White. Full Touch 3.5-inch LCD. Includes Power Supply.
    Print Type: Direct Thermal
    DPI:203
    Add-Ons:White Healthcare Plastic
    Interface:USB, Ethernet, Bluetooth, and WiFi
    PC45 Barcode Printer. Direct Thermal. Linerless Platten. 300 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. RFID Encoder, Media Low Sensor, & Full Touch 3.5-inch LCD. Includes Power Supply. Order Power Cord Separately.
    $1879.00 Add to Cart
    Print Type: Linerless Direct Thermal
    DPI:300
    Add-Ons:RFID Encoder & Low Media Sensor
    Interface:USB, Ethernet, Bluetooth, and WiFi
    PC45 Barcode Printer. Direct Thermal. 300 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. Healthcare White. Full Touch 3.5-inch LCD. Includes Power Supply.
    PC45, Desktop Printer, Thermal Transfer, 300 DPI, 4 inch label width, Ethernet, Full Touchscreen, No Power Cord (purchase separately), 1.0 inch Notchless Ribbon Adapters
    PC45 Barcode Printer. Thermal Transfer. 203 DPI. USB & Ethernet Interface. Full Touch 3.5-inch LCD. Includes Power Supply. Order Power Cord Separately.
    DPI:203
    Print Type:Thermal Transfer
    Interface:USB & Ethernet
    PC45 Barcode Printer. Direct Thermal. 300 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. Full Touch 3.5-inch LCD. Includes Power Supply & Power Cord.
    Print Type: Direct Thermal
    DPI:300
    Interface:USB, Ethernet, Bluetooth, and WiFi
    PC45 Barcode Printer. Thermal Transfer. 203 DPI. USB, Ethernet, Bluetooth, and WiFi Interface. RFID Encoder, Low Media Sensor & Full Touch 3.5-inch LCD. Includes Power Supply. Order Power Cord Separately.
    $1918.00 Add to Cart
    DPI:203
    Add-Ons:RFID Encoder & Low Media Sensor
    Print Type:Thermal Transfer
    Interface:USB, Ethernet, Bluetooth, and WiFi
    PC45 Barcode Printer. Direct Thermal. 203 DPI. USB & Ethernet Interface. RFID Encoder & Full Touch 3.5-inch LCD. Includes Power Supply & Power Cord.
    $1434.65 Add to Cart
    Print Type: Direct Thermal
    DPI:203
    Add-Ons:RFID Encoder
    Interface:USB & Ethernet
    PC45 Barcode Printer. Thermal Transfer. 300 DPI. USB & Ethernet Interface. Full Touch 3.5-inch LCD. Includes Power Supply & Power Cord.
    DPI:300
    Print Type:Thermal Transfer
    Interface:USB & Ethernet

    Accessories

    PC45D, Self-Strip Module with Label Taken Sensor
    PC45D, Platen Roller
    PD45D, Linerless Platen Roller
    PC45D, Linerless Cutter with Label Taken Sensor
    PC45D, Cutter With Media Present Sensor
    PC45D HC, Self-Strip Module with Label Taken Sensor
    4" Ribbon Take-Up Core For 4" Thermal Transfer Printers. 0.5" OD. (Three Pack)
    Honeywell Edge 3-Year Comprehensive Warranty. Gold for PC45 Barcode Printer
