POS-X EVO Laser

EVO Laser Barcode Scanner


The POS-X EVO Laser has reached end of life. It has been replaced by the Custom America ScanMatic.

This product replaces the older POS-X XI3200.

The POS-X EVO Laser barcode scanner offers aggressive scanning at an affordable price, great for retail scanning. Lightweight with an easy to use design, the EVO Laser barcode scanner is at home in medium volume retail scanning, such as home stores and department stores.

As the name implies, the barcode scanner is a 1D laser scanner, with an optimal scan range of half an inch to almost a foot for standard retail barcodes. A dual-color LED on the back of the scanner lets you know when the EVO Laser is ready to scan and when a barcode is successfully scanned, ideal for environments where the audible tone cannot or should not be heard.

POS-X built the EVO Laser to handle day-to-day retail use and abuse. The barcode scanner withstands drops of 1-meter, surviving accidental bumps off counters. The rubberized molding around the hood and base not only protects the EVO Laser from collisions but also prevents the scanner from damaging products with which it may collide. Shipping with a 5-year warranty with 2-day rapid replacement coverage standard, the POS-X EVO Laser barcode scanner will provide any retailer with many years of peace of mind.

    Features
  • 0.5" to 10" scan range for standard retail barcodes
  • 72 scan/sec scanning speed
  • Withstands multiple 1-meter drops
  • LED on scanner shines green when ready to scan, red on successful scan
  • Optional stand available

Product Specifications
Dimensions 2.8" x 6.5" x 3.7"
Weight 4.16 oz
Color Options Black
Interfaces Available USB
Scan Method 1D Laser Scanner
Decoding Capabilities Standard 1D Symbologies
Scan Rate (Maximum) 72 scans/sec
Reading Angle 46 degrees horizontal
Contrast Ratio 35% minimum
Typical Depth of Field 0.5" to 10" for 13 mil UPC-A
Auto Sense Mode Yes
Drop Specification 3.3-feet
Operating Temperature 32° to 104° F
Ambient Light (Max) 0 to 4842 Lux
Warranty 5 Year with 2-day rapid replacement turnaround
