Symbol DS6707

The pictures shown are general images for product DS6707 and may not be applicable to all part numbers

Buy it now
Lifetime Support
15 Day Return Period
DS6707 Features
Corded
2D / QR
Color Options

Cash Register White, Twilight Black

DS6707 Barcode Scanner


The Symbol DS6707 has reached end of life. It has been replaced by the Zebra DS8108.

The lightweight DS6707 barcode scanner combines the power to read 1D, 2D, PDF and postal symbologies with 1.3 megapixel image and document capture in a single device. Advanced data capture and text enhancement technology ensures readability of very small print in scanned document images, making the DS6707 an optimal choice for industries utilizing electronic filing systems such as heathcare and government agencies.

With the DS6707 laser scanner's built-in 360° omni-directional range, hand held scanning is a breeze -- just point and shoot. And don't worry about clumsy hands; the DS6707 barcode scanner survives multiple 6 foot drops to concrete. The optional hands-free stand allows easy presentation scanning at the point of sale with instant switching to handheld operation when necessary.

    Technical Specifications:
  • 650 nm LED Laser Diode
  • Weighs 6.4 oz.
  • Exports Images as JPG, BMP & Tiff
  • Reads all Common 1D, 2D & PDF Symbologies
  • Operating Temp. 32° - 122°
  • IP43 Water & Dust Resistance
  • Image Transfer at 12 Megabits/Sec.

See Accessories tab for optional hands-free stand.

Click Here for Additional Warranty Information

Product Specifications
Dimensions 6.55 in. H x 4.72 in. L x 2.82 in. W (16.6 cm H x 11.9 cm L x 7.1 cm W)
Weight 6.4 oz
Color Options Cash Register White
Twilight Black
Interfaces Available USB
RS232
Scan Method Area Imager
Decoding Capabilities Standard 1D, 2D, PDF, & Postal Codes
Mobility/Range Corded
Motion Tolerance Horizontal velocity: 5 in. (12.7) cm per second
Reading Angle Standard range (SR):
Roll: 360°
Pitch: ±65°
Skew: ±60°
Print Contrast (Min.) 25% minimum reflectance
Typical Depth of Field Standard range (SR):
5 mil (Code 39): 1.1 – 6.5 in. (2.8 – 16.5 cm)
13 mil (100% UPC/EAN): 0.5 – 9.7 in. (1.3 – 24.6 cm)
20 mil (Code 39): 0.5 – 15.2 in. (1.3 – 38.6 cm)
PDF417 (10 Mil): 0.9 – 7 in. (2.3 – 17.8 cm)
Datamatrix (10 Mil): 1.1 – 7.5 in. (2.8 – 19.1 cm)
Indicators Light
Beep
Auto Sense Mode Yes, In Stand
Image Capture DS6707-SRBU0100ZR Yes, as Document Capture Specific Model
Drivers License Data Parsing DS6708-DL20007ZZR Yes, as Drivers License Parsing Model
Mobile Phone Scanning Capabilites n/a
Healthcare Specific Model No
Operating Temperature 32° to 122° F / 0° to 50° C
Drop Specification Withstands multiple 6 ft. (1.8m) drops to concrete
Environmental Sealing IP43
Ambient Light (Max) Immune to normal artificial indoor and natural outdoor (direct sunlight) lighting
Stand 20-66483-02R Yes, Optional Intellistand
Warranty 5 Year Manufacturer Warranty

Symbol DS6707 Reviews

POSGuys Rating:

"The Symbol DS6707 would fit well into any medium to high volume retail environment. It has a good scan engine to handle damaged barcodes and bright lighting. An IP43 seal allows it to be protected from light dust and water."


Read the comprehensive Symbol DS6707 Review by POSGuys' Staff

Customer Reviews

Frequestly Asked Questions

Recommended Models

DS6707 2D Scanner Kit, Black Standard Range Scanner and 7ft. USB Straight Cable Included, USB Interface
Please Call
Color:Black
Interface:USB
DS6708 Barcode Scanner, Black with Drivers License Parsing Capability, Multi Interface [Cable Sold Separately - See Accessories]
Please Call
Color:Black
Interface:MULTI
Warning:Cable Not Included

Additional Models

DS6707 2D Scanner, White with Document Capture, USB/RS232 Interface [Cable Sold Separately - See Accessories]
Please Call
Color:white
Interface:USB/RS-232
Warning:Cable Not Included
DS6707 2D Scanner, Black with Document Capture, USB/RS232 Interface [Cable Sold Separately - See Accessories]
Please Call
Color:Black
Interface:USB/RS-232
Warning:Cable Not Included
DS6707 2D Scanner Kit, White Standard Range Scanner and 7ft. USB Straight Cable Included, USB Interface
Please Call
Color:White
Interface:USB
DS6707 2D Scanner Kit, Black Standard Range Scanner, 7ft. Straight Interface Cable, and Power Supply Included, RS-232/DB9F Interface
Please Call
Color:Black
Interface:RS-232
Accessories:Power Supply
DS6708 Barcode Scanner, White with Drivers License Parsing Capability, Multi Interface [Cable Sold Separately - See Accessories]
Please Call
Color:White
Interface:MULTI
Warning:Cable Not Included
DS6707 Barcode Scanner, White with DPM Scanning, [Cable Sold Separately - See Accessories]
Please Call
Color:White
Warning:Cables Not Included

Accessories

Intellistand for DS6700 Series; White
Intellistand for DS6700 Series; Black
Gooseneck Stand Assembly, Color: Black for the DS6XXX
Symbol 1-Year Service Center Warranty - Bronze Package (must be purchased within 15 days of scanner purchase)
Symbol 1-Year Advanced Exchange including Comprehensive Coverage (must be purchased within 15 days of scanner purchase)
Symbol 5-Year Service Center Warranty - Gold Package (must be purchased within 15 days of scanner purchase)
7-Foot RS232 Cable, Standard DB9 Female TxD on 2, Straight (Requires Power Supply)
USB Interface Cable (Original Part)

Previously Available Models
