Honeywell Granit Ultra 2100i
The pictures shown are general images for product Granit Ultra 2100i and may not be applicable to all part numbers
Granit Ultra 2100i Industrial Barcode Scanner
Granit Ultra scanners offer ultra scan performance, ultra durability, and ultra ease of use for premium productivity in rugged scanning applications from contact up to arm length (SR model) or 10m(33”) for 100mil C39 symbols (XR model).
Ultra Scan Performance
For a scanner to optimize productivity, it should read and transmit common barcodes nearly as fast as the user can pull the trigger, and Granit Ultra is engineered to do just that. Granit Ultra integrates high-speed processing, AI algorithms, and decoding enhancements to result in an average 45% scanning speed increase vs. Granit XP*, enabling improved productivity.
Ultra Durability
In modern warehouse, distribution center, and manufacturing environments, any scanner must be durable enough to survive harsh operating conditions. Under exactly that kind of rough treatment, Honeywell Granit Ultra is ready to deliver.
Ultra Ease of Use
Ready to operate right out of the box for many applications, Granit offers easy custom configuration in the time it takes to scan a barcode. For further workflow improvement, Granit can also read multiple codes in the field of view, organizing and outputting the data in a predefined order using Honeywell’s Data Format Editor.
| Product Specifications | |
|---|---|
| Dimensions (LxWxH) | 194.8mm × 75.8mm × 139.5mm (7.7 in × 3.0 in x 5.5 in) |
| Weight | 330g (11.64 oz) |
| Drop |
|
| Tumble | 7,500 1m (3.3ft) tumbles |
| Environmental Sealing | IP65 and IP68 |
| Decode Capabilities |
|
| ESD | +/-20KV air discharge, +/-8kV contact discharge, +/-8kV indirect coupling plane |
| Humidity | Up to 95% relative humidity, non-condensing |
| Operating Temperature | -30°C to 50°C (-22°F to 122°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Voltage | 4.0 VDC to 5.5 VDC |
| Interface | USB, Keyboard Wedge, RS-232 TTL (cables available to convert for +/-12V True use) |
| Field of View |
|
| Roll, Pitch, Skew | +/-360°, +/-65°, +/-65° |
| Illumination |
|
| Scan Pattern |
|
