Janam Technologies XP Series

The pictures shown are general images for product XP Series and may not be applicable to all part numbers

XP Series Mobile Barcode Scanner


This product replaces the older Janam Technologies XG100.

For mobile workforces dependent on applications built on the legacy Palm OS operating system, the XP Series hand held barcode scanners deliver a complete solution in a lightweight, yet rugged mobile barcode scanner. The XP Series is the only Palm OS mobile data collector on the market featuring optional 2D scanning capabilities.

Whether you're looking to replace discontinued Palm PDA terminals or deploying a new Palm OS barcode scanning solution, the XP Series mobile computers offer two powerful choices, the XP20 batch scanner with monochrome touch display, and the XP30 BlueTooth-enabled barcode scanner with a color touch display and optional 2D scanning capabilities.

    Technical Details:
  • 32MB SDRAM
  • 64MB NAND Flash Backup
  • Mini-SD Card Slot
  • Backlit Keypad
  • Omni-directional 1D Scanning Standard
  • RoHS Compliant
  • Long-life Rechargeable Li-ion Battery

The 2D scanning firmware update is available under Accessories.

Charging Note: The XP Series does not ship with charging or communications cables. We recommend JANAM-COMM-KIT for charging/communications.

Please note, Palm does not support USB connections to 64-bit PCs. We recommend using a serial interface cable with serial to USB adapter.

Product Specifications
Weight 9.88 oz (280 g)
Dimensions 1.2H x 3.11W x 5.75L in (30.5 x 79 x 146 mm)
Operating System Palm OS
Processor 266 MHz Freescale i.MX21
Memory 32 MB RAM, 64 MB Flash
Screen 2.17" x 2.95" LCD at 160 x 160 or 240 x 320
Seal Specification IP54
Battery 3.7V 2000 mAh Li-ion
Interface USB, 802.11b/g
Expansion miniSD slot
Operating Temperature 14° to 122° F
Humidity 5% to 95% non-condensing
Keyboard PDA keypad (with 4-way navigation) or numeric keypad
Scan Method Linear Imager or 2D Imager
Color Options Black

Janam Technologies XP Series Reviews

POSGuys Rating:

For operations looking to replace the discontinued Symbol SPT1500 and SPT1800 Palm OS terminals, Janam has the perfect solution with its XP20 and XP30 units. The ability to add 2D barcode scanning functionality with a simple firmware upgrade purchase is just icing on the cake!

Customer Reviews

Recommended Models

Batch Terminal, 1D Scanning, 160x160 Monochrome Display, 266MHz CPU, 32MB/64MB, PDA Keypad, Palm v5.4.9, 1880mAh Battery; Black
Color:Black
Screen Resolution:160x160 Monochrome
Keypad:PDA
Terminal:Batch
Batch Terminal, 1D Scanning, 160x160 Monochrome Display, 266MHz CPU, 32MB/64MB, Numeric Keypad, Palm v5.4.9, 1880mAh Battery; Black
Color:Black
Screen Resolution:160x160 Monochrome
Keypad:Numeric
Terminal:Batch
WLAN Terminal, 1D Scanning, 160x160 Monochrome Display, 266MHz CPU, 32MB/64MB, PDA Keypad, Palm v5.4.9, 1880mAh Battery: Black
Color:Black
Screen Resolution:160x160 Monochrome
Keypad:PDA
Terminal:WLAN

Additional Models

Batch Terminal, Black with 1D Scanning, 240x320 QVGA Color, 266MHz CPU, 32MB/64MB, Numeric Keypad, Palm v5.4.9, 1880mAh Battery
XP30 Batch Mobile Computer, No Scanner, PDA Keypad

Accessories

Extended Battery (3760mAh 3.7V) for XP20 / XP30 Terminals (Batteries must be shipped via ground shipping)
XM Series Four Slot Cradle Kit w/ Power Supply, Line Cord, USB
Please Call Add to Cart
Power Supply & Line Cord for XM Series Single-slot Cradle
Power Supply & Line Cord for XM Series 4-Slot Charging Cradle
Power Supply for UC-XP-1, SC-XP-1 and CC-XP-1 - Janam
3-Track Magnetic Stripe Reader for XM Series Terminals
Stylus (5-pack) for XM Series Terminals
Janam Universal Accessories Cable Cup (for the DEX/Printer Cables)
Janam Universal Accessories ONeil Printer Cable (Use with CC-XP-1)
2D Barcode Scanner Firmware Upgrade
USB Synching/Charging Cable for XP20 Terminals (Power Supply Required)
XP30/XM Series Communications Kit, Includes USB Charging/Sync Cable and Power Supply (parts CC-P-002U and AC-XP-1)
USB Synching/Charging Cable for XP30 and XM Terminals (Power Supply Required)
JANAM Serial Cable Cup Aseembly for XP20, Power Supply - AC-XP-1 IS REQUIRED to Charge a Device - **Replaces SC-XP-1**
JANAM, XP20, Single-Slot Charging Cradle Kit for XP20 Series, Serial/USB, (Includes cradle, power supply, line cord and communications cables). Replaces CK-XP-1S
