DataLogic Falcon X60/65
The pictures shown are general images for product Falcon X60/65 and may not be applicable to all part numbers
Falcon X60/65 Mobile Computers
Rugged Mobility Without Compromise
Falcon X60/X65 is Datalogic’s ultra‑rugged mobile computer engineered for warehouse operations where continuous data capture, operational uptime, and fast decision making are essential.
Designed for high‑intensity workflows across retail distribution, manufacturing, and transportation & logistics, Falcon delivers the performance, durability, and connectivity required to keep supply chains moving without interruption.
Performance That Keeps Operations Moving
Modern warehouses cannot afford slowdowns caused by missed reads, unstable connections, or device downtime. Falcon X60/X65 is engineered specifically to support scan‑heavy environments where every second impacts throughput.
Powered by the Qualcomm Dragonwing™ QCM4490 processor, Falcon provides fast application response and reliable multitasking across demanding workflows. Built on Datalogic’s Android™ platform with support for up to 10 years of operating system updates, it offers long‑term investment protection and simplified lifecycle management.
Long‑range scanning capabilities enable barcode capture up to 20 meters, helping operators work more efficiently while reducing unnecessary movement across warehouse aisles and staging areas.
Confident Scanning at Every Distance
Falcon X60/X65 combines Datalogic’s advanced scanning technologies to improve operator speed, focus, and accuracy during intensive daily operations.
Green Spot™ good‑read feedback, visible up to 10 meters, provides immediate visual confirmation even in large warehouse spaces, while TrueAim™ dual‑level trigger technology helps operators perform fast and precise long‑distance reads with greater confidence.
The result is smoother scanning workflows with reduced interruptions and fewer repeated scans.
Designed for Tough Working Conditions
Falcon X60/X65 is purpose‑built for environments where devices are exposed to drops, vibration, dust, moisture, and changing temperatures.
Its ultra‑rugged construction protects operational continuity across warehouse floors, loading docks, outdoor yards, ports, and transportation hubs.
A high‑brightness display and ergonomic keypad design support comfortable operation during extended shifts, while optional pistol grip configurations improve handling during repetitive scanning activities.
With up to 53 large, glove‑friendly physical keys, Falcon supports fast and accurate data input even in workflows where touchscreen interaction is less practical.
Always Connected, Indoors and Outdoors
Falcon X60/X65 is designed to maintain stable communication across complex warehouse and logistics environments.
Wi‑Fi 6 and 5G connectivity support seamless transitions between indoor facilities and outdoor operational areas, enabling reliable real‑time access to enterprise applications and operational data.
Whether managing inventory movements, shipment verification, traceability workflows, or yard operations, Falcon helps teams stay connected and responsive throughout the workday.
Enterprise Visibility and Secure Mobility
Falcon X60/X65 integrates with Datalogic Mobility Suite and the forthcoming Datalogic Connect™ cloud‑based IoT platform, enabling centralized management of enterprise device fleets.
Organizations can remotely configure devices, deploy firmware updates, monitor operational status, and integrate seamlessly with WMS, ERP, and inventory management platforms.
Security is embedded throughout the platform, reflecting Datalogic’s European approach to cybersecurity and support for GDPR‑driven data protection requirements.
Key Features
- Ultra-rugged industrial mobile computer
- Qualcomm Dragonwing™ QCM4490 processor
- Android™ platform with up to 10 years OS support
- Long-range scanning up to 20 m
- Green Spot™ good-read feedback visible up to 10 m
- TrueAim™ dual-level trigger technology
- Wi-Fi 6 and 5G connectivity
- Up to 53 glove-friendly physical keys
- High-brightness display and ergonomic keypad
- Integrated pistol grip support
- Integration with Datalogic Mobility Suite and Datalogic Connect™
Ready for the Demands of Modern Warehousing
Falcon X60/X65 combines rugged reliability, advanced scanning performance, secure connectivity, and enterprise mobility management into a powerful platform built for modern supply chain operations.
From high‑volume distribution centers to complex industrial workflows, Falcon helps organizations improve productivity, maintain operational continuity, and support long‑term digital transformation strategies.
| Product Specifications | |
|---|---|
| Battery | Removable extended battery pack with rechargeable LiIon batteries; MicroUSB type-C for fast battery charging. 3.63 V; Rated 7,000 mAh typical (25.445 Watt-hours); Hot Swap for application data protection |
| Wireless Charging | WPC Qi EPP compatible; 10W charging |
| Drop Resistance | Multiple 2.8m/9.2ft drops to concrete at ambient temperature per MIL STD 810H; Multiple 2.4m/7.9ft drops to concrete over operating temp (-20°C to 50°C/-4°F to 122°F) per MIL STD 810H |
| Tumbles | 4000 1.0m/3.3 ft tumbles at room temperature, meets and exceed IEC 60068-2-32 Procedure 2 specification; |
| Particulate and Water Sealing | IP65 and IP68 with battery, per IEC60529 specification |
| Temperature | Operating: -20 to 50 ºC / -4 to 122 ºF Storage/Transport: -30 to 70 ºC / -22 to 158 ºF |
| ESD | 15 kV air discharge / 8 kV contact discharge |
| Dimensions | Handheld: 232 x 80 x 42 mm / 9.13 x 3.15 x 1.65 in Pistol Grip: 232 x 80 x 165 mm / 9.13 x 3.15 x 6.50 in |
| Weight | Handheld: with battery: 550 g / 19.4 oz Pistol Grip, XLR: with battery 700 g / 24.7 oz |
| Primary Display | 4.3-inch LCD A-Si IPS - WVGA 480 x 800 resolution; LED backlight and integrated touch screen; High brightness for Indoor and Outdoor High Visibility - 600 NITS typical |
| Touch Panel | Touch Screen: 5 points multi-touch capacitive panel with hardened Corning® Gorilla® Glass Victus® and optical bonding; Support for gloves and stylus; water drops rejection and anti-fingerprint surface finishing |
| Keyboard | Physical Keyboards: 31-key Numeric; 41-key Functional Numeric; 53-key Alphanumeric; Keyboard with backlight Physical Keys: 2 side scan keys; Power On/Off Software keys: 3 Android soft keys |
| Trigger | TrueAimTM professional two-stage trigger |
| Camera | Rear Camera: 13-megapixel resolution; Auto focus Illumination: user controllable LED flash (torch mode); Front Camera: 8-megapixel resolution; Fixed focus |
| Scan Engine | Halogen™ DE2121-DL 1D/2D scan engine; Halogen™ DE2121-ER Extended Range 1D/2D scan engine; Halogen™ DE2172 Extra-long Range 1D/2D scan engine; Datalogic’s ‘Green Spot’ for good-read feedback on all scan engines; visible up to 10m for Extra-long Range |
| Vibration | Software programmable for duration and intensity |
| Accelerometer | 3-Axis accelerometer to detect orientation |
| Gyroscope | Senses angular velocity |
| Ambient Light | Auto adjusts display backlight |
| Proximity | Auto deactivates display when close to face |
| Magnetometer | e-compass for direction and orientation detection |
| Barometer | Atmospheric pressure / Z-location (Falcon X65 only) |
| Interfaces | High Speed USB 3.2 gen1 Host and Client (Type-C); Super Speed USB 2.0 (Type-C, Bottom I/O); Gigabit Ethernet connectivity (via multi-slot dock) |
| Microphones | 2 mics, with noise cancellation |
| Loudspeaker | Speaker for handsfree data calls and audio application |
| Warranty | 1-Year Factory Warranty |
DataLogic Falcon X60/65 Reviews
Customer Reviews
Recommended Models
Falcon X60 Hand held, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 31-Key Numeric, Contactless, Standard Range 2D Imager w/Green Spot, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, hand-strap, keyboard overlays
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 41-Key Functional Numeric, Contactless, XLR 2D Imager w/Green Spot, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Additional Models
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 31-Key Numeric, Long Range 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 31-Key Numeric, Standard Range 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 31-Key Numeric, XLR 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 41-Key Functional Numeric, Standard Range 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 41-Key Functional Numeric, XLR 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 53-Key Full Alphanumeric, Long Range 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 53-Key Full Alphanumeric, Standard Range 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
Falcon X60 Pistol Grip, Wi-Fi6E, 4.3" display GG7, 8GB RAM/128GB Flash, 53-Key Full Alphanumeric, XLR 2D Imager w/Green Spot feedback, Camera (13MP), Front Camera (8MP), Android 15. Includes: GMS, battery 7000 mAh, lanyard, keyboard overlays.
