DataLogic Memor 12-17

The pictures shown are general images for product Memor 12-17 and may not be applicable to all part numbers

Buy it now View Accessories

POSGuys Rating:Not Rated

Lifetime Support

1 Year Warranty

15 Day Return Period

Free Shipping

Memor 12-17 Features

Android

4ft Drops

IP68

Description
Specs
Review
Downloads

Memor 12-17 Mobile Computers

Standard Features for the Memor 12/17 Include:

Connectivity: Wi‑Fi 6/6E, Cellular 5G (select models), Bluetooth, NFC
Display: 6.0" color Full High Definition+ (1080 x 2160); ~450 nits; Corning® Gorilla® Glass 7; multi‑mode capacitive touch with glove/stylus support and water‑drop rejection
Battery: 1‑piece swappable, rechargeable Li‑Ion; USB‑C fast charge; Qi EPP wireless charging (7 W); Enterprise Battery Saver
Scan Engine: Halogen 2121DL 1D/2D with Green Spot feedback and DeepSight™ decoding; GS1 Digital Link–ready
Camera: 13‑megapixel rear camera (LED flash), 8‑megapixel front‑facing camera

CPU: Qualcomm® QC4490 octa‑core, up to 2.4 GHz
Memory: 6 GB RAM/64 GB Flash; Swap memory adds virtual RAM headroom for smooth multitasking
Operating System: Android™ 13 with GMS; platform upgradable to Android 18
Drop Specifications: Multiple 4 ft/1.3 m drops to concrete at room temperature; up to 5 ft/1.5 m with protective boot per MIL‑STD‑810H
Tumble Specification: 500 tumbles, 1.6 ft/0.5 m; 500 tumbles, 3.3 ft/1.0 m with optional protective boot
Sealing: IP68 and IP65, with battery per applicable IEC sealing specifications

Slim and ultra‑thin enterprise‑class devices for front‑facing applications

Memor 12‑17 is designed for comfort and durability during full‑shift use, meeting MIL‑STD‑810H for drop/tumble and using Gorilla® Glass 7 for enhanced scratch and drop protection.

Fast and easy scanning for every type of environment

Halogen 2121DL with Green Spot and DeepSight™ decoding gives quick, confident reads in challenging lighting and on worn labels. The platform is GS1 Digital Link–ready.

Productivity and connectivity redefined

QC4490 plus Swap memory keeps apps responsive. Workers get modern wireless: Wi‑Fi 6/6E across the line and 5G on select Memor 17 models, plus fast GNSS for field navigation.

Charging and NFC, your way

Top up via USB‑C, use wired enterprise cradles for data/charge, or go contactless with Qi wireless‑charging cradles. Multi‑side NFC supports tap‑to‑pay and credential workflows.

Mobility, sustainability and EASEOFCARE

Extended platform support (Android 13 → 18), regular updates via Datalogic Shield, eco‑minded accessories and packaging, and flexible EASEOFCARE coverage.

Product Specifications
Local Area Network (WLAN)	Wi-Fi 6e IEEE 802.11 a/b/g/n/ac/ax and 802.11 d/e/h/i/k/r/ v/w/mc; Frequency range: Country dependent, typically 2.4 GHz,5 GHz and 6 GHz bands; 2x2 MIMO; WPA3 Enterprise 192-bit mode supported
Personal Area Network (WPAN)	Bluetooth wireless technology v5.3 (Classic Bluetooth wireless technology and BLE)
NFC Communication	Support for the following standards: Tag types 1/2/3/4/5 (ISO14443-4 A/B; ISO15693; Mifare; Felica) Card emulator. Contactless payments and Apple ECP protocol supported.
WWAN / Cellular	Memor 17 LTE-Advanced / 4G+; NR 5G FR1; 3GPP Rel.16; EMEA and ROW Configuration: GSM: Quad band; WCDMA: B1/2/4/5/8; FDD_LTE: B1/2/3/4/5/7/8/17/19/20/ 25/28/66; B34/38/39/40/41/42/43; 5G: n1/2/3/5/7/8/20/2 5/28/38/40/41/66/77/78/79; North America Configuration (AT&T and Verizon certified): GSM: 850/1900; WCDMA: B2/4/5; FDD_LTE: B2/ 4/5/7/12/13/17/19/25/26/29/30/66; TDD_LTE: B38/41/48; 5G: N2/5/7/12/13/25/26/29/30/38/41/66/71/77; VoLTE, VoNR and Wi-Fi calling enabled
Global Positioning System (GPS)	Integrated Assisted-GPS (A-GPS) Supported Types: GPS Dual Band, Galileo Dual Band, BeiDou Dual Band
Battery	1-piece swappable battery pack with rechargeable Li-Ion batteries; 3.87V; 4,000 mAh typical (14.98 Watt-hours)
Wireless Charging	WPC Qi EPP compliant; 7W charging
Drop Resistance	Multiple 1.3/4ft drops to concrete across operative temperature without rubber boot per enterprise standard according to MIL STD 810H. Multiple 1.5m/6ft drops to concrete over operating temp (-10°C to 50°C/14°F to 122°F) with rubber boot according to MIL STD 810H.
Tumbles	500 0,5m/1.6 ft tumbles at room temperature without protective boot, meets and exceed IEC 60068-2-32 Procedure 2 specification. 500 1m/3.2 ft tumbles at room temperature with rubber boot, meets and exceed IEC 60068-2-32 Procedure 2 specification.
Sealing	IP65 and IP68 with battery, per IEC60529 specification
Chemical Resistance	General purpose chemical cleansers: “Water solution of Sodium Hypochlorite” “Windex Multisurface / Glassex with ammonia” “Formula 409, Glass and Surface cleaner / Glassex with ammonia” “Ethyl alcohol” “Isopropyl alcohol” “Hydrogen peroxide”
Temperature	Operating: -10 to 50 ºC / 14 to 122 ºF Storage/Transport: -40 to 70 ºC / -40 to 158 ºF
ESD	15kV air discharge / 8kV contact discharge
Dimensions	165 x 76.7 x 13.5 mm / 6.49 x 3.0 x 0.53 in
Primary Display	6.0 inch LTPS in 18:9 format - FHD+ resolution 1080x2160; LED backlight; 450 NITS
Keys	Physical Keys: 2 side scan keys; PTT; Power On/Off; Volume Up/ Down; 3 Android soft keys
Touch Panel	Touch Screen: 5 points multi-touch capacitive panel with hardened Gorilla Glass 7 and optical bonding; Support for gloves and stylus; water drops rejection and antifingerprint surface finishing
Weight	With Battery: 245 g/8.6 oz
Camera	Rear Camera: Resolution: 13 megapixel; Auto focus Illumination: User controllable LED flash (torch mode); Front Camera: Resolution: 8 megapixel; Fixed focus
Scan Engine	Halogen™ DE2121-DL 1D/2D scan engine; Datalogic’s ‘Green Spot’ for good-read feedback
Sensors	Vibration: Software programmable for duration and intensity Accelerometer: 3-Axis accelerometer to detect orientation Gyroscope: Senses angular velocity Ambient Light: Auto adjusts display backlight Proximity: Auto deactivates display when close to face Magnetometer: e-compass for direction and orientation detection Barometer: Atmospheric pressure / Z-location (Memor 17 only)
Interfaces	High Speed USB 3.2 gen1 Host and Client (Type-C); Super Speed USB 2.0 (Type-C, Bottom I/O)
Audio	Microphones: 2 mics, with noise cancellation Loudspeaker: Speaker for handsfree calls and audio application Receiver: Speaker for voice calls
SIM Slots	1 Nano SIM; 1 eSIM
Expansion Slots	1 Micro SD card (up to 2TB)
Memory	RAM Model 6GB: 6 GB on-chip RAM, plus an optional 2 GB SWAP Memory (using flash storage as extra RAM, activated through a setting). UFS Flash Storage: 64 GB (both models)
Microprocessor	Qualcomm QCx4490 Octa-core 2.4 GHz
Operating System	Android 13, upgradeable to Android 18
Real-Time Clock	Time and date stamping under software control
Warranty	1-Year Factory Warranty
