Honeywell Dolphin 7800

The pictures shown are general images for product Dolphin 7800 and may not be applicable to all part numbers

Buy it now
Lifetime Support
15 Day Return Period
Dolphin 7800 Features
Color Options

Black, Healthcare White

Dolphin 7800 Mobile Computers

The Honeywell Dolphin 7800 has reached end of life. It has been replaced by the Intermec CN51.

This product replaces the older Honeywell Dolphin 9700.

The Honeywell Dolphin 7800 mobile computer offers enterprise-class usability at a great price, fantastic for mobile sales and field service teams. Designed with the latest in scanning and wireless technology, the Dolphin 7800 allows you to get work done wherever necessary.

Adaptus 6.0 Imaging Technology, in your choice of standard or extended range imaging, gives the Dolphin 7800 provides the aggressive and fast scanning ideal for fast-paced environments. The standard range imager offers up to 20" of scanning, fantastic for easily reading barcodes during inventory management or shipping applications. For additional data capture, such as shipment verification, the Dolphin 7800 can also come equipped with a 3 megapixel camera.

The Dolphin 7800 comes with a variety of wireless configurations, ensuring you only pay for the wireless technology you need. All models come standard with 802.11a/b/g/n and Bluetooth radios, making it a great choice for data management within the four walls. Optional models ship with software switchable cellular radios, allowing you to jump from GSM to CDMA with a flip of a switch.

Though built as an enterprise device, the Dolphin 7800 is still strong enough to hold up to industrial or hospital use. An IP54 seal on the Dolphin 7800 protects it from windblown dust and splashes of water, ideal for wipedowns between uses. Honeywell buit the Dolphin 7800 to withstand multiple 5-foot drops to concrete plus over 1,600 3.3-foot tumbles, more than other mobile computers in its class. The healthcare-specific model utilizes special plastics resistant to the harmful effects of harsh cleaning agents, extending the life of your mobile computer.

• Windows Mobile 6.5
• 800 MHz TI OMAP Processor
• 256 MB RAM, 512 MB Flash
• Adaptus 6.0 Imager (N5603-SR or N5603-ER)
• 3.5" VGA LCD touchscreen
• Operates in temperatures as low as 14° F
• Can switch between GSM and CDMA networks on-the-fly
• Available in heath-care approved plastic body

Dolphin 7800 models with Android OS are available.
Product Specifications
Weight Standard Battery: 11.4 oz
Extended Battery: 13.4 oz
Dimensions Standard Battery: 6.2" x 3.0" x 1.1"
Extended Battery: 6.2" x 3.0" x 1.3"
Operating System Windows Mobile 6.5
Processor 800 MHz TI OMAP
Memory 256 MB RAM, 512 MB Flash
Screen 3.5" LCD at 640 x 480 VGA
Seal Specification IP54
Battery Standard: 3.7 V 2300 mAh
Extended: 3.7 V 4000 mAh
Camera 3 megapixel autofocus camera with LED flash (optional)
Interface USB, Bluetooth, 802.11a/b/g/n
Cellular Radio GSM (Voice and Data): 3.9G–HSPA+ (800/850/1900/1700/2100 MHz), GSM/GPRS/EDGE (850/900/1800/1900 MHz)
CDMA (Voice and Data): EVDO Rev A - 1xRTT/EVDO (800/1900 MHz)
Software definable Gobi 3000 (Data only): 3.9G – HSPA+/UMTS (800/850/900/1700/1900/2100MHz), GSM/GPRS/EDGE (850/900/1800/1900MHz) and EVDO Rev A - 1xRTT/EVDO (800/1900 MHz)
Expansion MicroSD Slot
Operating Temperature 14° to 122° F
Humidity 10% to 95% Non-Condensing
Drop Specification Withstands 5-foot drops to concrete
Keyboard 30-key numeric, 46-key QWERTY
Scan Method 2D Imager (Standard or Extended Range)
Color Options Black
Healthcare White
