UniTech PA690

PA690 Mobile Computers


The UniTech PA690 has reached end of life.

This product replaces the older UniTech PA600.

The Unitech PA690 mobile computer offers a rugged design and unique feature set ideal for field service, delivery, and data management inside or outside the four walls. 802.11a/b/g and BlueTooth radios come standard, making it easy to maintain data connections while indoors. Optional models come equipped with additional GPS and GSM/GPRS, turning the PA690 into a fantastic route management and field service solution.

At 3.8" diagonal, the PA690's screen is the largest in the industry, giving you full 800 x 480 WGA resolution. This extended space is fantastic for route delivery services, maximizing displayable data during signature capture. The crisp display is also reactive to ambient light, automatically adjusting screen brightness to maintain easy reading and extend battery life.

Unitech built the PA690 to withstand rough and demanding environments, reinforcing it against damage that would take out lesser mobile computers. The body is built to withstand drops of 5-feet, excellent if knocked out of an employee's hand or off the seat of a truck. Environmental sealing gives the PA690 an IP65 seal rating, completely sealing internal components against dirt and protecting it from low pressure jets of water. With a 1-year standard warranty and optional extended coverage, the Unitech PA690 is a fantastic industrial mobile computing solution.

Features
• Windows Mobile 6.5
• 806 MHz Marvell PXA320 Processor
• 256 MB RAM, 512 MB Flash
• Largest in industry 3.8" WVGA touchscreen
• Optional gun grip for easy use
• Power and interface cables included

Everything you need to get connected is included with the PA690.
Product Specifications
Weight 13.76
Dimensions 2.9" x 1.6" x 7"
Operating System Windows Mobile 6.5
Processor 806 MHz Marvell PXA320
Memory 256 MB RAM, 512 MB Flash
Screen 3.8" TFT LCD at 800 x 480 (WVGA)
Seal Specification IP65
Battery Standard: 3.7 V 2200 mAh, Extended: 3.7 V 4000 mAh
Interface USB, Bluetooth, 802.11a/b/g
Cellular Radio 3.5G Five Band: GSM/GPRS, UMTS WCDMA/HSDPA, GPRS Edge
Expansion MicroSD Slot
Operating Temperature 14° to 122° F
Humidity 5% to 95% non-condensing
Drop Specification Withstands 6-foot drops to concrete
Keyboard 44-Key QWERTY or 26-Key Numeric
Scan Method 1D Laser Scanner
Color Options Grey

UniTech PA690 Reviews

POSGuys Rating: Not Rated

test

Customer Reviews

This product has not been reviewed yet, be the first to share your experience

Add a customer product review

Accessories

PA690-AZ1 PA690 Extended Warranty, 48-hour Turnaround and 2-Day Air Shipment, 1 Year Contract $187.00 Add to Cart
PA690-AZ2 PA690 Extended Warranty, 48-hour Turnaround and 2-Day Air Shipment, 2 Year Contract $272.00 Add to Cart
PA690-AZ3 PA690 Extended Warranty, 48-hour Turnaround and 2-Day Air Shipment, 3 Year Contract $347.00 Add to Cart
PA690-Z1 PA690 Extended Warranty, 5-Day Turnaround and Ground Shipment, 1 Year Contract $170.00 Add to Cart
PA690-Z2 PA690 Extended Warranty, 5-Day Turnaround and Ground Shipment, 2 Year Contract $285.00 Add to Cart
PA690-Z3 PA690 Extended Warranty, 5-Day Turnaround and Ground Shipment, 3 Year Contract $331.00 Add to Cart
1400-900001G PA690 Replacement Battery, 2200 mAh (Batteries must be shipped via ground shipping) $70.00 Add to Cart
1400-900005G PA690 Extended Life Battery, 3.7 V, 4000 mAh (Requires Battery Door Part # 604143G) (Batteries must be shipped via ground shipping) $105.00 Add to Cart
1550-900043G PA690 Replacement Communications/Charging Cable, USB Interface (Power Supply Not Included) $35.00 Add to Cart
5000-900005G PA690 USB Desktop Cradle, 1-Bay with Bay for Spare Battery Charging, Includes USB Cable, Uses PA690 Power Supply for Charging $105.00 Add to Cart
5100-603493G PA690 4-Slot Battery Charger (Requires Power Supply Part # 1010-601551G) $157.00 Add to Cart
5500-900005G PA690 Gun Grip $84.00 Add to Cart
604143G PA690 Extended Battery Door (Compatible with Battery Part# 1400-900005G) $17.00 Add to Cart
1010-601959G Unitech Universal Power Supply $42.00 Add to Cart

Previously Available Models

PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, Numeric Keypad, USB Interface Cable, Power Cable, 802.11b/g, Bluetooth Radios
This model has reached end of life.
Please Call
PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, 5 Megapixel Camera, QWERTY Keypad, USB Interface Cable, Power Cable, 802.11b/g, Bluetooth Radios
This model has reached end of life.
Please Call
PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, 5 Megapixel Camera, Numeric Keypad, USB Interface Cable, Power Cable, 802.11b/g, Bluetooth Radios
This model has reached end of life.
Please Call
PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, 5 Megapixel Camera, QWERTY Keypad, USB Interface Cable, Power Cable, GPS, 802.11b/g, Bluetooth, GPRS Radios
This model has reached end of life.
Please Call
PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, 5 Megapixel Camera, Numeric Keypad, USB Interface Cable, Power Cable, GPS, 802.11b/g, Bluetooth, GPRS Radios
This model has reached end of life.
Please Call
PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, 5 Megapixel Camera, QWERTY Keypad, USB Interface Cable, Power Cable, GPS, 802.11b/g, Bluetooth, GPRS Radios (Includes SIM Card with 6-Month Data Plan)
This model has reached end of life.
Please Call
PA690 Mobile Computer, Grey with Windows Mobile 6.5, Laser Scanner, 5 Megapixel Camera, Numeric Keypad, USB Interface Cable, Power Cable, GPS, 802.11b/g, Bluetooth, GPRS Radios (Includes SIM Card with 6-Month Data Plan)
This model has reached end of life.
Please Call
