Zebra HC2X/HC5X Mobile Computer

The pictures shown are general images for product HC2X/HC5X Mobile Computer and may not be applicable to all part numbers






HC2X/HC5X Mobile Computer Mobile Computers
Empower Clinical and Non-Clinical Healthcare Workers to Improve Efficiency, Task Accuracy And Patient Outcomes
- Connectivity: Wi-Fi 6e (select models), Cellular 5G (select models), Bluetooth, NFC
- Display: 6.0 in. color Full High Definition+ (1080 x 2160), 450 NITS; Corning® Gorilla® Glass
- Battery: User removable; rechargeable Li-Ion; 3800mAh/14.63Wh; standard capacity with BT BLE; PowerPrecision for real-time battery metrics; fast charge; true hot swap (HC50/HC55)
- Scan Engine:SE4720 1D/2D Scan Engine with White Illumination/Green Aimer Occasional barcode scanning available via camera; barcode decoding software included
- Camera: 13-megapixel rear camera, 8-megapixel front-facing camera
- CPU: Qualcomm® 5430 hex-core, 2.1 GHz
- Memory: HC20/HC25: 6 GB RAM/64 GB UFS Flash
HC50/HC55: 8 GB RAM/128 GB UFS Flash - Operating System: Upgradeable to Android 16
- Drop Specifications: Multiple 4 ft (1.25m) drops to tile over concrete across temperature (+14F to +122F/-10C to +50C) per MIL-STD 810H
- Tumble Specification: 500 tumbles, 1.6 ft (0.5m)
- Sealing: IP68 and IP65, with battery per applicable IEC sealing specifications
Zebra’s newest family of rugged healthcare mobile computers, the Wi-Fi only HC20 and HC50, purpose built to deliver all the features healthcare workers need to improve efficiency, accuracy, the quality of patient care and patient outcomes. As Zebra’s thinnest and lightest healthcare mobile computers, the Wi-Fi HC20/HC50 and Wi-Fi/5G HC25/HC55 provide the perfect balance of ergonomics, features and cost. Your workers get a pocketable device that is easy to carry, easy to use, easy to disinfect and easy to manage. There’s a model for every healthcare workflow – clinical and non-clinical staff, from hospitals and clinics to patient homes.
Perfectly Designed on the Outside for Healthcare
The Ergonomics Every Healthcare Worker Wants
Zebra’s thinnest and lightest healthcare mobile computers are perfectly balanced to minimize hand fatigue. Contoured surfaces and sculpted lower bumpers reduce pressure points and provide any size hand with a secure grip — and all day comfort.
Built for Constant Disinfecting
The disinfectant-ready design offers advanced medical grade plastics that support the widest selection of disinfectants in the industry. And a specially designed housing and USB-C port plug minimize crevices where pathogens can accumulate.
20% More Display Space to See More — and Scroll Less
The high resolution, 6 in, FHD+ edge-to-edge display is bright and easy to read in virtually any lighting. And it works with the thin gloves typically worn by healthcare workers.
Call for Help with a Press of the Emergency Alert Button
This programmable dedicated button can be configured to call a specific number or launch an application in emergency or duress situations, with an activation sequence that prevents false alarms.
One Set of Accessories for All Models
Make carrying easy with the disinfectant-ready healthcare carry clip or hand strap. There are cradles designed for the backroom, a desk or a nurses station, plus extra batteries to ensure power for back-to-back shifts and a screen protector that boosts display durability.
Unbeatable Battery Features
No need to take these devices out of service to charge — if the battery runs low, just swap in a fully charged battery. With true hot swap, you can change batteries without impacting device functionality — no missed calls, no missed notifications, no lost data. PowerPrecision technology provides real-time metrics to monitor battery health, so you can easily spot and replace batteries that can no longer hold a full charge. And you can use any standard USB-C charge cable for charging flexibility.
Perfectly Designed on the Inside with Advanced Mobile Technologies to Boost Productivity and Care Quality
Flexible Options for World-Class Split-Second Scanning
Choose the right device for your workers. The integrated scanner is ideal for scan-intensive healthcare workflows. Workers can easily capture barcodes on patient wristbands, medication vials, supplies, medical equipment, food trays and more — even if barcodes are damaged or poorly printed. The white illumination and green LED aimer are patient friendly, safe for use in any healthcare or home healthcare environment. Or, the high-resolution camera and Zebra scanning software are perfect for occasional barcode capture.
Capture High-Resolution Photos with the 16 MP Rear Camera
From clinical workers capturing wound condition to non-clinical workers documenting facility rounding, a picture is worth a thousand words. With the easy capture of high resolution photos, workers can spend less time explaining — and more time on crucial tasks.
Power Today’s Healthcare Apps
Healthcare workers use graphics-intensive applications — from clinicians visualizing patient vital signs remotely and viewing imaging studies to maintenance engineers accessing detailed equipment schematics. These powerful devices can handle it all with a faster processor, large memory space and 2TB MicroSD card slot.
Out-of-the-Box Capture of Unique Device Identifier (UDI) Barcodes
Instantly check to see if medical equipment has been recalled before use, protecting patient safety. Easily capture charges for all items, protecting the bottom line. And inventory visibility is complete and more accurate, eliminating risky out of stocks.
The Fastest, Most Dependable Wireless Connections
Advanced wireless technology keeps workers seamlessly connected whether they are inside the hospital, traveling to a patient’s home or roaming between campus medical facilities. The HC20 (Wi-Fi 6) and HC50 (Wi-Fi 6E) are ideal for staff who work inside your facility. With support for 5G and Private 5G, the HC25 and HC55 are ready for the latest clinical collaboration advancements using high-speed private and hybrid 5G systems.
Enhance Communication with AI Noise Suppression
Clear communication is vital to delivering exceptional patient care. Utilizing advanced neural networks, Zebra’s AI noise suppression algorithms help ensure crystal clear voice on every call, even if workers are in a noisy environment — from a busy emergency room to hospital hallways or moving between buildings.
Turn Devices Into Two-Way Radios and PBX Handsets
Empower your workers with multiple voice-calling capabilities — push-to-talk (PTT) communications and the ability to place and accept PBX calls. Nurses can reach a physician instantly or take a call from a family member. And Profile Manager gives staff the ability to cover multiple roles and departments.
Secure Text Messaging — When Audio Calls Aren’t Appropriate
Comply with privacy laws that protect patient information with text messaging that is secure and auditable — unlike text messaging on the cellular public network.
High Quality Video Conferencing for Superior Collaboration
Enable remote telehealth consultations with physicians, pharmacists and other caregivers through the HC5X’s 5 MP front facing camera.
Android ‘Plus’ — Enhanced with Enterprise Capabilities
Support for future versions of Android ensures that the devices you purchase today will support the new features of Android well into the future. Deploy ‘no touch’ updates on your schedule with Zebra Zero Touch. Control availability of GMS services on your devices to increase security. Add over 100 features to make Android truly enterprise-ready. LifeGuard for Android ensures the latest security patch is always installed, while putting you in control over how and when devices are updated.
The Zebra-Only Difference — Everything You Need to Build a Truly Complete Healthcare Mobility Solution
Zebra DNA
Simplify every aspect of device management and give workers time-saving tools that improve productivity with this comprehensive collection of applications that contain many no-cost tools.
Zebra Guardian — Optimize Device Availability and Access Control
Ensure workers have ready-to-use devices at the start of each shift with Zebra Guardian, a complete and configurable portfolio that optimizes how devices are stored, accessed, tracked and managed. Securely store and charge devices in Guardian Cabinets. Give workers streamlined and secure device access via Identity Guardian. And Device Guardian makes it easy to locate misplaced devices, even if the device is turned off or the battery is depleted.
Create a Mobile-Driven Workstation with Workstation Connect
When tasks require a larger screen, keyboard, mouse and printer, just insert the HC2X/HC5X into a Connect Cradle to create a fully-featured mobile-driven workstation — ideal at nurses stations, on portable ‘computers on wheels’, ward hubs and more.
Product Specifications | |
---|---|
Dimensions | 6.5 in L x 3.0 in W x 0.49 in D
(165mm L x 76.3mm W x 12.5m D) |
Weight | HC20/HC25: 8.4 oz (239g)
HC50/HC55: 8.5 oz (242g) |
Display | 6.0 in. color Full High Definition+ (1080 x 2160), 450 NITS; Corning® Gorilla® Glass |
Imager Window | Corning Gorilla® Glass |
Touch Panel | Multi mode capacitive touch with bare or light gloved fingertip input |
Backlight | LED backlit |
Power | User removable; rechargeable Li-Ion; 3800mAh/14.63Wh; standard capacity with BT BLE; PowerPrecision for real-time battery metrics; fast charge; true hot swap (HC50/HC55) |
Expansion Slot | Supports up to 2TB MicroSD |
SIM | HC25/HC55: 1 Nano SIM and 1 eSIM (except China) |
Network Connections | WWAN (HC25/HC55), WLAN, WPAN, USB 3.1 (Bottom Type C) - Super Speed (host and client) |
Notifications | Audible tone; multi-color LEDs; vibration |
Keypad | On-screen keypad |
Voice and Audio | Multiple microphones with noise cancellation; dual speakers for loudness; Bluetooth wireless headset support; high quality speaker phone; HD Voice, including Superwideband (SWB), Wideband (WB) and Fullband (FB) |
Buttons | Dual dedicated scan buttons; programmable button for PTT or other use; volume up/down |
Safety/Alert | Red Alert Button with emergency dialer feature |
CPU | Qualcomm® 5430 hex-core, 2.1 GHz |
Operating System | Upgradeable to Android 16 |
Memory | HC20/HC25: 6 GB RAM/64 GB UFS Flash
HC50/HC55: 8 GB RAM/128 GB UFS Flash |
Drop Specification | Multiple 4 ft (1.25m) drops to tile over concrete across temperature (+14F to +122F/-10C to +50C) per MIL-STD 810H |
Tumble | 500 tumbles, 1.6 ft (0.5m) |
Sealing | IP68 and IP65, with battery per applicable IEC sealing specifications |
Interactive Sensor Technology (IST) | Light sensor, magnetometer, motion sensor with gyro, pressure sensor (select SKUs only) and proximity sensor |
Camera | Rear: 16 MP; HC50/HC55 only: Front 5 MP |
Scanning | SE4720 1D/2D Scan Engine with White
Illumination/Green Aimer
Occasional barcode scanning available via camera; barcode decoding software included |
NFC | YES |
Radio | IEEE 802.11 a/b/g/n/ac/ax/d/h/i/r/k/v/w/mc;
2x2 MU-MIMO; Tri-band (2.4 GHz, 5 GHz, 6
GHz);
Wi-Fi CERTIFIED 6™ (Wi-Fi 6E5); Dual Band
Simultaneous; IPv4, IPv6 |
Wireless WAN (HC25/HC55) | North America: 5G FR1: n2/5/7/12/13/14/25/2 6/29/38/41/48/66/71/77/78; 4G: B2/4/5/7/12/1 3/14/17/25/26/29/38/41/48/66/71; 3G: B2/4/5; Rest of World: 5G FR1: n1/2/3/5/7/8/20/28/38/40/41/66/71/77/78; 4G: B1/2/3/4/5/7/8/13/17/20/28/38/39/40/41/ 42/43/66/71; 3G: 1/2/4/5/8; 2G: 850/900/1800/1900; China/Japan: 5G FR1: n1/3/5/7/8/28/38/40/41/77/78/79; 4G: B1/3/5/7/8/19/18/26/28/34/38/39/40/41/42; 3G: B1/5/6/8/19; 2G: 850/900/1800; Dual SIM/Dual Standby, VoLTE, Gigabit LTE-A, 5G NR Sub-6 (NSA, SA), LTE/NR Carrier Aggregation, supports private networking (LTE/5G) |
Bluetooth | Class 2, Bluetooth v5.2 with BLE beaconing |
Disinfecting and Cleaning | Highly disinfectant ready; Healthcare plastics — supports 30+ wipes and disinfectants. For information on Zebra-approved disinfectants and guidelines on cleaning HC2X/HC5X devices, please download the Cleaning and Disinfecting Fact Sheet at www.zebra.com/healthcare-mobile-computers |
Warranty | 1 Year |
