Custom America MP Ranger
The pictures shown are general images for product MP Ranger and may not be applicable to all part numbers
MP Ranger Mobile Printers
MP Ranger is a latest generation mobile printer and represents the evolution of Custom's range of mobile printers. It can print on thermal paper in roll format. Complete with sensors for displaying status and battery level, it allows the printing of 1D and 2D barcodes (QRCODE). It can handle rolls with paper width of 76.2 mm or 80 mm using the special reducer included in the package, and is designed to be used in outdoor working contexts, thanks to the IP54 protection to resist splashing of liquids and dust for use in adverse weather conditions and resistance to falls from 1 meter.
The operational equipment is completed by a clip for belt fastening and as an accessory the practical case with shoulder strap is available for greater protection and the cradles, with 1 or 5 positions for practical charging. The printer is equipped with different charging options, from simple connection via USB Type-C to positioning on single or multi-position charging cradles up to five units. MP Ranger can be connected to any mobile device, from simple phones, to specialized terminals, to handheld mobile computers and tablets with Bluetooth and Wi-Fi functionality thanks to the Wireless technology.
| Product Specifications | |
|---|---|
| Resolution | 203 dpi |
| Max. Print Speed | 110 mm/sec |
| Character Set | PC437, PC850, PC860, PC863, PC865, PC866, PC858 (euro), Cinese esteso GB 18030-2000, Koreano PC949 |
| Supported Media | Continuous paper and label with gap/notch |
| Roll Width | 76,2mm and 80mm |
| Roll Diameter | max 40mm |
| Printing Width | 72 mm |
| Emulation | CUSTOM/POS |
| Interfaces | USB type-C 2.0 Full Speed Wifi 802.11 b/g/n Bluetooth 4.2 BLE |
| Graphic Memory | 3 MB for logos (maximum width 576 dot) + 5 MB per font |
| Drivers | Windows® (32/64 bit) – only on request WHQL and silent installation |
| Battery | Li-ion 7.2 V 2.6 Ah 18.72 Wh |
| MTBF | 3246 hours (electronic board) |
| Print Head Life | 50Km / 100 M pulses (12.5% pulses) |
| Dimensions (L x W x D) | 149(L) x 53(H) x 122(P) mm |
Custom America MP Ranger Reviews
Customer Reviews
| Downloads |
|---|
| MP Ranger Data Sheet |
