Datecs PP-55
The pictures shown are general images for product PP-55 and may not be applicable to all part numbers
PP-55 Mobile Printers
The Datecs PP-55 has reached end of life. It has been replaced by the Datamax-O'Neil microFlash 2t / 2te.
The PP-55 operates with a variety of PDAs. The PDA is placed into a cradle on top of the printer. Belt-clip carrying cases ("holsters") are available which allow the printer with the loaded PDA to be slipped into the case , as well as custom holsters designed for specific printer/PDA combinations.Paper: 58mm wide (2.25") (~ 60 feet per roll)
Internal rechargeable Li-ion battery pack
AC Adapter included
With fully charged battery, can print approximately 450 feet of data (~about 8 rolls)
32 and 42 column fonts
Clamshell design for easy paper loading
Software package for printing data from applications running on the handheld device
Software Development Kit (SDK)
Mag stripe version available (Depth and width added to mag stripe reader)
Faster processor that will support the upcoming Barcode Scanner, Smart Card reader and USB host versions.
Ability to charge both printer and PDA/Smartphone when connected to AC or DC power source.
Reliability 50km wear
Operating temp 0-45 degrees C
One year warranty
Lightweight 15 oz.
The PP-55 features a low price and a fast (50mm per second) print speed utilizing a state of the art fixed head thermal printer mechanism.
Here are some of the features:
***Windows Vista Drivers Currently not Available***
To ensure order accuracy, please make sure to let your sales representative know which handheld device you will use with the PP-55
| Product Specifications | |
|---|---|
| Dimensions | 195 mm L x 50 mm H x 87 mm W |
| Weight | 390 g (including battery and paper) |
| Color Options | Grey |
| Interfaces Available | RS-232 USB |
| Print Method | Thermal Printer |
| Print Speed | 50 mm per second |
| Resolution | 203 dpi - Horizontal and Vertical |
| Barcodes Supported | Standard 1D Barcodes as well as PDF417 |
| Graphics Printing | 1 Black & White BMP format ( 1-bit per pixel) Size: 384 x 240 |
| Data / Logo Storage | RAM 1Mb |
| Magnetic Card Reader | PP-55MS Optional 3 Track Reader |
| Barcode Scanner | PP-55MSBC Yes, Optional |
| Print Head Life | 50 km |
| Paper Dimensions | 57.5 ± 0.5 mm wide |
| Paper Thickness | 0.06 ~ 0.10 mm |
| Operating Time | ~ 4 Rolls (Alpha-numeric data) |
| Operating Temperature | -10°C to 45°C |
| Storage Temperature | -25°C to 70°C @ |
| Warranty | One year warranty |
Datecs PP-55 Reviews
Customer Reviews
| Downloads |
|---|
| Manual |
| Quick Start Guide |
