Elo TouchSystems 15L Series
The pictures shown are general images for product 15L Series and may not be applicable to all part numbers
Dark Grey
15L Series POS Touch Screen Monitor
Elo 15", 17" & 19" Touchscreen Monitors
The Elo 1515L, 1715L and 1915L standard-format touchscreen monitors are built to withstand the rigors of continuous public use with a rugged, built-for-touch design. Their stylish, thin, modern look—paired with a retail-focused feature set—makes them a strong fit for commercial touchscreen monitor deployments.
Designed for versatility, these displays can register inputs from a finger, gloved hand or soft stylus with fast, accurate response. Each model is available with Elo’s proven touch technologies and multiple mounting options to support a wide range of application environments.
Integrated touch.
The 15"/17"/19" desktop LCD touchmonitor family is available with a choice of Elo’s single-touch AccuTouch® five-wire resistive or IntelliTouch® surface acoustic wave (SAW) technologies—both offered with a dual serial/USB touch interface.
.png)
Flexible mounting.
The Elo 15"/17"/19" touchscreen monitor family offers multiple mounting options to support installation flexibility, including wall- and pole-mounting via standard VESA mount patterns, as well as tabletop accommodations using the included desktop stand. Capped through-mount holes on the base help enable tabletop security where required.
.png)
Commercial grade.
These touchscreen monitors deliver the quality and reliability Elo is known for and are backed by a three-year standard warranty. Elo products undergo rigorous reliability testing (over 20 tests) to deliver 50,000 MTBF.
.png)
Other features.
- Consumer-grade pricing with Elo commercial-grade reliability
- Designed for touch use with a stable tilt stand
- Long-lasting product cycle
- Sealed touchscreen against dirt, dust and liquid
- Dual serial/USB interface
- Removable stand and VESA mounting option
- Mounting holes on stand bottom for tabletop security
- Controls on the side rather than the front, plus lockout function for public use
- Digital on-screen display (OSD)
- Worldwide agency approvals
- Three-year standard warranty
| Product Specifications | |
|---|---|
| Display Type | 19 Inch Active Matrix TFT LCD |
| Color Options | Dark Grey |
| Interface | USB or Dual Serial/USB |
| Style | Desktop - Stable Tilt Base |
| Optimal Resolution | 1280 x 1024 at 60 or 75 Hz |
| Aspect Ratio | 5:4 |
| Contrast Ratio | 800:1 (typical) |
| Brightness | LCD panel: 300 nits - with AccuTouch: 240 nits - with APR: 270 nits - with IntelliTouch: 270 nits |
| Colors | 16.7 million colors with dithering |
| Weight | 17.42 lb (7.90 kg) |
| Dimensions | 16.9 (w) x 15.21 (d) x 8.15 (h) in. |
| Mounting Options | Removable base; 100 mm VESA mount; threaded-through mounting holes, under base |
| Operating Temperature | 0°C to 40°C |
| Power Supply | Internal, with jack to accept power from optional external brick |
| Monitor Input Voltage | AC input (line) voltage: 85-265 VAC, 47-63 Hz - DC input (line) voltage: 12.0 VDC ±0.75V |
| Power Dissipation | 50 W max |
| Warranty | 3 Years |
