Elo TouchSystems 2201L

The pictures shown are general images for product 2201L and may not be applicable to all part numbers

Buy it now
Lifetime Support
15 Day Return Period
2201L Features
16:9 Ratio
Splash Proof
Color Options


2201L POS Touch Screen Monitor

The Elo TouchSystems 2201L has reached end of life. It has been replaced by the Elo TouchSystems 02 Series (22-27 in.).

*While stock is available on a first-come-first-served basis, the 2201L has reached End of Life. Please contact our Sales Team for more information.

The 2201L touch monitor features flexible, space-saving design, high definition wide-aspect ratio 22 inch LCD touchscreen and Windows 7 multi-touch interactivity. This touch monitor is suited to meet durability and aesthetic needs for back office, front of store, kiosk and out of store applications, Elo's new 2201L offers the ultimate versatility for a variety of retail, business or hospitality interactive systems.
  • Multi-touch capability
  • Wide 22 inch display screen
  • 3 year warranty
  • Standard USB interface
Product Specifications
Display Type Active matrix TFT LCD, Multi-Touch
Color Options Black
Screen 22" Diagonal, 18.8" x 10.6" (477mm x 268mm)
Aspect Ratio 16:9
Optimal Resolution 1920x1080
Brightness LCD Panel: 250 nits; with IntelliTouch Plus: 225 nits
Colors 16.7 million
Contrast Ratio 1000:1
Dimensions 21.7" x 7.6" x 15.4" (551mm x 193mm x 392mm) max
Weight Unpackaged: 16.5lbs (7.5kg)
Packaged: 27.6lbs (12.5kg)
Mounting Options VESA 4-hole 100mm mounting interface on rear of unit
4-hole 200x100mm threaded mounting on bottom of stand
Operating Temperature 32°F to 104°F
Power Drawn 22W-29W
Monitor Input Voltage 12VDC ± 5%
Optional Peripherals Web Camera
Speakers Two 2W speakers
Warranty 3 Year
MTBF 50,000 hours demonstrated
