MicroTouch Mach Digital Signage
The pictures shown are general images for product Mach Digital Signage and may not be applicable to all part numbers
Mach Digital Signage POS Touch Screen Monitor
M1 DS Series 4K PCAP Touch Monitors
The M1 DS Series are 4K interactive touch monitors designed for modern digital signage, kiosks, and collaboration spaces. Available in 49", 55", and 65", each model features a UHD 3840 x 2160 panel, up to 500 nits of brightness, and a projected capacitive touch system that supports high-point multi-touch and stylus input.
A durable front glass with IP65 front-side protection helps these displays stand up to heavy public use, while multiple video inputs and USB touch interfaces make integration with PCs, media players, and controllers straightforward. With flexible VESA mounting, integrated speakers, and support for continuous operation, the M1 DS Series delivers a consistent, responsive touch experience across all three sizes.
Featured Specifications
- Sizes: 49", 55", and 65" 4K touch monitors
- Maximum Resolution: 3840 x 2160 (UHD)
- Contrast Ratio: 1100:1
- Aspect Ratio: 16:9
- Brightness: 500 nits (No Touch), 450 nits (P-CAP)
- View Angle: H: 178°, V: 178°
- Touch: Projected capacitive, multi-touch with stylus support
- Video Ports: 2 x HDMI, 1 x DisplayPort, 1 x VGA
- Connectivity: 2 x USB-B for touch, 1 x USB-A, RS232, LAN, audio in/out, SPDIF
- Front Bezel: Edge-to-edge glass with IP65 front-side protection
M2 DSN Series 4K Non-Touch Signage Displays
The M2 DSN Series are professional 4K non-touch signage displays built for always-on commercial environments. Available in 49" and 55", each model delivers a UHD 3840 x 2160 image, 500 nits of brightness, and a 16:9 panel with wide viewing angles for clear, impactful content in public spaces.
Fanless operation and 24/7 duty-cycle support make the M2 DSN Series well-suited for retail, transportation, hospitality, and corporate messaging. Connectivity includes multiple HDMI and DisplayPort inputs, VGA, RS232, audio in/out, and network control options, giving integrators the flexibility to tie these displays into existing AV and digital signage platforms.
Featured Specifications
- Sizes: 49" and 55" 4K signage displays
- Maximum Resolution: 3840 x 2160 (UHD)
- Contrast Ratio: 1200:1
- Aspect Ratio: 16:9
- Brightness: 500 nits
- View Angle: H: 178°, V: 178°
- Video Ports: 2 x HDMI, 1 x DisplayPort, 1 x VGA
- Control & Audio: RS232, RJ45, audio in/out, SPDIF out
- Duty Cycle: Fanless design rated for 24/7 operation
