Custom America Ascent
The pictures shown are general images for product Ascent and may not be applicable to all part numbers
_800_600.png "Alternate image for Ascent"){kind=small}
Buy it now
View Accessories
Lifetime Support
15 Day Return Period
Ascent Features
16:9 Ratio
Windows
Ascent POS Computers
This product replaces the older Logic Controls SB1015.
Reliable Performance in a Compact Footprint
A compact, retail-hardened POS terminal built for flexible deployments and long service life.
ASCENT combines a low-profile design with 11th-generation Intel Celeron or Core i5 processor options for retail, hospitality, grocery, convenience, and entertainment applications. Its 15.6-inch Full HD projected-capacitive touchscreen delivers a bright, durable operator interface.
Extensive connectivity supports a wide range of point-of-sale peripherals, while accessible memory and storage help simplify service and future upgrades. The collapsible stand keeps the terminal compact for installation and transport.
15.1″ / 15.6″ PCAP
Windows 10/11 • Linux • No OS
Celeron J6412 • Core i5
Key Specifications
Display
15.6-inch Full HD widescreen or 15.1-inch standard-format touch display, depending on model
Touch
True-flat projected-capacitive multi-touch
Processor
Intel Celeron J6412 or Core i5-1145G7E
Memory / Storage
8–16 GB DDR4 / 128–256 GB M.2 SSD
Operating System
Windows 10 IoT, Windows 11 IoT/Pro, no OS, or Linux
Connectivity
USB-A/USB-C, serial, LAN, and RJ11 cash drawer; Wi-Fi and Bluetooth on selected models
Expansion / Mounting
Modular bezel peripherals, collapsible stand, and 100 × 100 mm VESA
What's in the Box
Custom ASCENT 15.6-inch POS terminal
Power supply
| Product Specifications | |
|---|---|
| Processor | Intel Celeron J6412; Intel Core i5-1145G7E |
| TPM | TPM 2.0 |
| Memory | 8 GB to 16 GB DDR4 |
| Storage | 128 GB to 256 GB M.2 SSD |
| Supported OS | Windows 10 IoT; Windows 11 IoT; Windows 11 Pro; Linux |
| Display | 15.6-inch TFT LCD |
| Resolution | 1920 x 1080 |
| Touch Screen | True-flat projected capacitive multi-touch |
| Brightness | 500 nits |
| I/O | Celeron: 1 x front USB-A 2.0, 2 x USB-A 3.0, 4 x USB-A 2.0, 1 x USB-C 3.0, 3 x RJ48 (with 2 RJ48-to-DB9 cables), 1 x RJ45, 1 x RJ11, 1 x FeDP, 1 x 4-pin with latch Core i5: 1 x front USB-A 2.0, 4 x USB-A 3.0, 2 x USB-A 2.0, 1 x USB-C 3.0, 3 x RJ48 (with 2 RJ48-to-DB9 cables), 1 x RJ45, 1 x RJ11, 1 x FeDP, 1 x 4-pin with latch |
| Wireless | Wi-Fi and Bluetooth on selected configurations |
| Speaker | 1 x 3 W |
| Camera | 5 MP front camera on premium model |
| Power Supply | 65 W / 19 V (Celeron); 120 W / 19 V (Core i5) |
| Dimensions | 368 mm (W) x 265 mm (H) x 233 mm (D) with collapsible stand |
| Weight | 3.5 kg (stand + screen); 5 kg with packaging and included cables |
| VESA Mount | 100 x 100 mm |
| Warranty | 3 years |
Custom America Ascent Reviews
This durable, versatile POS computer delivers reliable performance with a sleek design and multiple display options for any environment. For lower price point POS terminals, check out the Custom America Daytona
Customer Reviews
| Downloads |
|---|
| Custom America Ascent Data Sheet |
Recommended Models
Ascent 15.6-inch Standard POS Touch Computer. i5 1145G7E. 8GB RAM. 128GB. Win 10 IoT. WiFi & Bluetooth Connectivity.
$2316.35 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
Connectivity:WiFi & Bluetooth
OS:Win 10 IoT
Processor: i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.1" Standard POS Touch Computer. i5 Processor. 8GB RAM. 256GB. Win10IoT. WiFi & Bluetooth Connectivity.
$1976.71 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 10 IoT
Processor:i5
Storage:256GB
Screen Size:Standard
Ascent 15.1" Standard POS Touch Computer. i5 Processor. 8GB RAM. 256GB. Win11Pro. WiFi & Bluetooth Connectivity.
$2165.01 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 Pro
Processor:i5
Storage:256GB
Screen Size:Standard
Ascent 15.6-inch Standard POS Touch Computer. i5 1145G7E. 8GB RAM. 256GB. Win 11 Pro. WiFi & Bluetooth Connectivity.
$2315.07 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 Pro
Processor:i5
Storage:256GB
Screen Size:Wide Screen
Additional Models
Ascent 15.6" Value POS Touch Computer. Celeron J6412, 8GB RAM, 128GB, Win 10 IoT.
Please Call Before Ordering
$1192.81 Add to Cart
RAM:8GB
Connectivity:Ethernet Only
OS:Win 10 IoT
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Value POS Touch Computer. Celeron J6412. 8GB RAM. 128GB. Win 11 Pro.
Please Call Before Ordering
$1260.07 Add to Cart
RAM:8GB
Connectivity:Ethernet Only
OS:Win 11 Pro
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Value POS Touch Computer. i5 1145G7E, 8GB RAM, 256GB, No OS.
Please Call Before Ordering
$2067.80 Add to Cart
RAM:8GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:i5
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Value POS Touch Computer. i5 1145G7E, 8GB RAM, 256GB, Win 10 IoT.
Please Call Before Ordering
$2201.45 Add to Cart
RAM:8GB
Connectivity:Ethernet Only
OS:Win 10 IoT
Processor: i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.6" Premium POS Touch Computer. i5 1145G7E, 16GB RAM, 256GB, Win 10 IoT WiFi, Bluetooth, PUSB Connectivity. Front Camera.
Please Call Before Ordering
$2520.53 Add to Cart
RAM:16GB
Add-Ons:Powered USB Port & Front-Facing Camera
Connectivity:WiFi & Bluetooth
Connectivity:WiFi & Bluetooth
OS:Win 10 IoT
Processor: i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.6" Standard POS Touch Computer. Celeron J6412. 8GB RAM. 128GB. Win 11 Pro. WiFi & Bluetooth Connectivity.
$1401.18 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 Pro
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Premium POS Touch Computer. Celeron J6412. 8GB RAM. 128GB. No OS. WiFi, Bluetooth PUSB Connectivity. Front Camera.
Please Call Before Ordering
$1135.47 Add to Cart
RAM:8GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.1" Standard POS Touch Computer. Celeron J6412 Processor. 8GB RAM. 128GB. No OS. WiFi & Bluetooth Connectivity.
$1040.22 Add to Cart
RAM:8GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:Celeron
Storage:128GB
Screen Size:Standard
Ascent 15.1" Standard POS Touch Computer. Celeron J6412 Processor. 8GB RAM. 128GB. Win11Pro. WiFi & Bluetooth Connectivity.
$1302.02 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 Pro
Processor:Celeron
Storage:128GB
Screen Size:Standard
Ascent 15.1" Standard POS Touch Computer. i5 Processor. 8GB RAM. 256GB. No OS. WiFi & Bluetooth Connectivity.
$1899.18 Add to Cart
RAM:8GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:i5
Storage:256GB
Screen Size:Standard
Ascent 15.1" Standard POS Touch Computer. Celeron J6412 Processor. 8GB RAM. 128GB. Win11IoT. WiFi & Bluetooth Connectivity.
$1112.80 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 IoT
Processor:Celeron
Storage:128GB
Screen Size:Standard
Ascent 15.1" Standard POS Touch Computer. i5 1145G7E. 8GB RAM. 256GB. Win11IoT. WiFi & Bluetooth Connectivity.
$2063.07 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 IoT
Processor:i5
Storage:256GB
Screen Size:Standard
Ascent 15.6" Standard POS Touch Computer. Celeron 6412, 8GB RAM, 128GB, Win 11 IoT, WiFi & Bluetooth Connectivity.
$1183.51 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 IoT
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Standard POS Touch Computer. i5 1145G7E, 8GB RAM, 256GB, Win 11 IoT, WiFi & Bluetooth Connectivity.
$2214.39 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 IoT
Processor:i5
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Standard POS Touch Computer. Celeron J6412, 8GB RAM, 128GB, No OS, WiFi & Bluetooth Connectivity.
$1033.49 Add to Cart
RAM:8GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6-inch Standard POS Touch Computer. Celeron J6412. 8GB RAM. 128GB. Win 10 IoT. WiFi & Bluetooth Connectivity.
$1188.95 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 IoT
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Premium POS Touch Computer. Celeron J6412 Processor. 8GB RAM. 128GB. Win 11 Pro. WiFi, Bluetooth, PUSB Connectivity. Front Camera.
Please Call Before Ordering
$1400.21 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 11 Pro
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Standard POS Touch Computer. i5 1145G7E Processor. 8GB RAM. 256GB. No OS. WiFi & Bluetooth Connectivity.
$2034.36 Add to Cart
RAM:8GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.6" Premium POS Touch Computer. i5 1145G7E Processor. 16GB RAM. 256GB. No OS. WiFi, Bluetooth, PUSB Connectivity. Front Camera.
Please Call Before Ordering
$2230.06 Add to Cart
RAM:16GB
OS:No OS
Connectivity:WiFi & Bluetooth
Processor:i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.6" Premium POS Touch Computer. i5 1145G7E Processor. 16GB RAM. 256GB. Win 11 Pro. WiFi, Bluetooth, PUSB Connectivity. Front Camera.
Please Call Before Ordering
$2520.53 Add to Cart
RAM:16GB
Connectivity:WiFi & Bluetooth
OS:Win 11 Pro
Processor:i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.6" Value POS Touch Computer. Celeron J6412, 8GB RAM, 128GB, No OS.
Please Call Before Ordering
$993.20 Add to Cart
RAM:8GB
OS:No OS
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6" Value POS Touch Computer. i5 1145G7E Processor. 8GB RAM. 256GB. Win 11 Pro.
Please Call Before Ordering
$2277.49 Add to Cart
RAM:8GB
OS:Win 11 Pro
Processor:i5
Storage:256GB
Screen Size:Wide Screen
Ascent 15.6-inch Standard POS Touch Computer. Celeron J6412. 8GB RAM. 128GB. Win 10 IoT. WiFi & Bluetooth Connectivity.
$1188.96 Add to Cart
RAM:8GB
Connectivity:WiFi & Bluetooth
OS:Win 10 IoT
Processor:Celeron
Storage:128GB
Screen Size:Wide Screen
Ascent 15.6-inch Standard,i5 1145G7E,16GB,256GB,Win 11 IoT,WiFi,BT
$2417.86 Add to Cart
RAM:16GB
Connectivity:WiFi & Bluetooth
OS:Win 11 IoT
Processor:i5
Storage:256GB
Screen Size:Standard
Accessories
MSR for Ascent All-in-One Terminal. 3 Track. Connects via IO ports on side of terminal.
$97.02 Add to Cart
LCM Customer Display for Ascent All-in-One Terminal. 2-Line. Connects to IO port on top of terminal.
$124.74 Add to Cart
Fingerprint Reader for Ascent All-in-One Terminal. Connects to IO port on side of terminal.
$221.76 Add to Cart
Custom America 3 Year CustomCare Advanced Exchange Warranty For Ascent, Daytona, and Peak 15" All-In-One Computers.
$230.00 Add to Cart
Custom America 5 Year CustomCare Advanced Exchange Warranty For Ascent, Daytona, and Peak 15" All-In-One Computers.
$384.00 Add to Cart
11.6" Touch LCD Rear Display for Custom America Ascent & Peak All-In-Ones.
$429.66 Add to Cart
