Home » POS Computers » Elo TouchSystems X-Series - 15 inch

Elo TouchSystems X-Series - 15 inch

The pictures shown are general images for product X-Series - 15 inch and may not be applicable to all part numbers

X-Series - 15 inch POS Computers

The Elo TouchSystems X-Series - 15 inch has reached end of life. It has been replaced by the Elo TouchSystems EloPOS System - 15 Inch.

This product replaces the older Elo TouchSystems 15B1.

The Elo 15-inch X-Series is an innovative, all-in-one, standard-aspect touchscreen computer that offers a sleek form factor with flexibility, power and endless configuration possibilities. With a compact design, the X-Series is ideal for applications in any retail, self-service or hospitality environment that requires a small footprint POS terminal or kiosk. The highly versatile platform provides maximum configurability and offers you unprecedented freedom of choice in the design of your AiO system.

The Elo X-Series 15" touchscreen computers are now available in three touch technologies ensuring you get the right computer to get the job done. Elo's AccuTouch® micro-bezel 5-wire resistive is ideal for restaurants where everything from pens to wet fingers are used to input data. For light retail the IntelliTouch® surface acoustic wave (SAW) will work nicely with bare fingers and the IntelliTouch Pro Projected Capacitive (PCAP) is great for gloved or bare hands and would be the best choice for warehouses and high volume retail.

Rigorously tested and backed by a three-year warranty, the X-Series touchscreen computer delivers superior quality and reliability. The splash-proof housing and rugged retail-hardened design easily withstand the adverse conditions associated with most commercial environments. The unique, modular chassis provides easy access to storage and memory for quick, tool-less service.

Product Specifications
Diagonal Size 15'' diagonal, Active matrix TFT LCD (LED)
Control Buttons Power, brightness up, brightness down, volume up, volume down Security Lockouts: Power and Control buttons lock.
Aspect Ratio 4:3
Active Area (mm) 11.97" x 8.98" / 304.12mm x 228.1mm
Resolution 1024 x 768 @ 60Hz
Number of Colors 16.2 million
USB Ports X2 & X3 Models: 2 x USB 3.0 on I/O 4 x USB 2.0 (2 on I/O, 2 on USB Front Access) X5 & X7 Models: 4 x USB 3.0 on I/O 2 x USB 2.0 (USB Front Access) All Models: 3 x USB 2.0 on edges for optional Elo peripherals
Serial Ports 1 x Serial RS-232 (standard), 1 x RJ45 (Native serial), 2 additional on Expansion Module
Ethernet Port 1 x LAN RJ45 (Gigabit)
Wireless 802.11 b/g/n
Bluetooth BT 4.0
Cash Drawer Port 12V/24V Cash Drawer Port on Expansion Module (24V default; selectable by BIOS setting)
Additional Video Out 2nd VGA output
2nd VGA output 1 x 3.5 mm Line out, 1 x 3.5 mm MIC in
Speakers Two 2W internal speakers
Weight (with stand) 15.17 lbs / 6.89 kg
Operating Temperature 0°C to 35°C / 32°F to 95°F
Mounting Options 100mm VESA mount or secure base to tabletop/desktop

Elo TouchSystems X-Series - 15 inch Reviews

POSGuys Rating:

Best selling model from the biggest all-in-one pos computer manufacturer. This highly configurable and versatil model has a variety of different processors, hard drive, and screen options. The stand also can be set in a high and low position. While it is not all metal or has an ip seal it is very well made and will work great in most environments.
