Elo TouchSystems 70L Series
The pictures shown are general images for product 70L Series and may not be applicable to all part numbers
70L Series POS Touch Screen Monitor
This product replaces the older Elo TouchSystems 2270L.
Elo 70-Series 22", 24" & 27" Touchscreen Monitors
The Elo 2270L (22"), 2470L (24"), and 2770L (27") Full HD touchscreen monitors deliver a commercial-grade interactive solution with a clean, minimalistic design that fits virtually any space.
Backed by a three-year warranty, each model features an energy-efficient TouchPro® PCAP touchscreen with clear or anti-glare scratch-resistant glass options, low blue light and flicker-free viewing comfort, dual built-in speakers, and simple connectivity with VGA, DisplayPort, and HDMI. With black and white finish options plus flexible mounting, the 70-Series is well-suited for POS, interactive digital signage, self-service, document signing, and more.
The bezel just got smaller.
The 2270L 22” touchscreen offers up to a 70% reduction in the bezel compared to similar models, helping you build sleek, space-efficient installations with a modern, edge-to-edge look.
Minimalistic design to fit any space.
With a clean aesthetic and streamlined profile, the 70-Series looks at home in customer-facing environments and operational workspaces alike. Standardize across sizes while maintaining a consistent, modern appearance throughout your deployment.
Set it up your way.
- From 20 degrees to 70 degrees, angle the display where you want it.
- Place it on a desktop, mount it on a wall or configure it to fit your space with VESA-compatibility.
- Built-in speakers and integrated I/O.
Navigate the OSD directly on the touchscreen.
We have made it easier to manage your On-Screen Display (OSD) controls — now you can use the touchscreen or the controls you are used to on the rear side of the monitor.
| Product Specifications | |
|---|---|
| Diagonal Size | 27" / 685.8 mm |
| Touch Technology | TouchPro PCAP |
| Aspect Ratio | 16:9 |
| Active Area | 23.54" x 13.24" / 597.888 mm x 336.312 mm |
| Display Resolution | 1920 x 1080 @ 50, 60Hz More Supported. See Spec Sheet for more. |
| Viewing Angle | Horizontal: 89°/89° or 178° total; Vertical: 89°/89° or 178° total |
| Brightness | Panel: 300 nits; with TouchPro PCAP: 270 nits |
| IO Ports | AC Input (IEC60320 C6), Audio in/out, VGA, HDMI, DisplayPort, USB 2.0 Type B, 2x USB 2.0 Type A |
| Dimensions | 24.65" x 14.68" x 1.72" / 626.2 mm x 372.8 mm x 43.8 mm |
| Weight | 13.89 lbs / 6.3 kg |
| Operating Temperature | Operating: 0° C to 40° C / 32°F to 104°F, Storage: -20° C to 60° C / -4°F to 140°F |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | VESA 4-hole 100mm mounting interface on rear of unit |
| Warranty | 3 years |
| Impact Protection | IK07 |
| What's In the Box | 2770L Touchmonitor
Quick Install Guide HDMI cable Touch USB cable NA Power cable EU Power cable EEI Label (EU) 2x EEI Label (UK) 2x Replace foot cover 5x Cable tie |
