POS-X ION TP5

ION TP5 POS Computers


The POS-X ION TP5 is an all in one touch screen computer that can be configured to include an integrated printer, bringing POS-X's powerful computers to the compact point of sale market.

Designed only in appearances to feel like those other compact POS systems, POS-X has designed an incredibly durable touch computer that can be configured with a thermal printer for that space saving look that is in demand today. Not wanting to compromise power for size, POS-X built the ION TP5 with an Intel Atom Z3735F 1.86GHz Quad Core processor with 32GB SSD hard drive and 2GB DDR3 memory. The 14" widescreen LCD display with P-CAP technology has an IP54 rating making it splash resistant thus great for both restaurants and retailers. Backed by POS-X's 3 Year free 2-day Advance Exchange service, the TP5 is a lasting investment in an emerging market.

    Features
  • 14″ widescreen LCD panel and projected capacitive (PCAP) TruFlat touch screen technology
  • Intel Atom Z3735F up to 1.86GHz Quad Core Processor
  • IP54 Seal Specification
  • Optional Built-In Thermal Receipt Printer
  • Small Foot Print 14.3” x 7.8” x 13.4”
  • 3 Year 2-Day Advance Exchange Warranty
Product Specifications
Dimensions 14.3” x 7.8” x 13.4”
Weight 9.2 lbs (4kg)
Tilting Angle 90°
CPU Intel Atom Z3735F up to 1.86GHz Quad Core
Hard Drive 32GB SSD
Memory 2GB DDR3
Ports USBx4; COM; LAN
Seal Specification IP54: Splash Resistant Screen
Operating Temperature 32°F to 95°F
Display 14″ Widescreen LCD (1366 x 768)
Screen TOUCH: P-CAP
Warranty 3YR Warranty

Frequestly Asked Questions

Downloads

POS-X ION TP5 Reviews

POSGuys Rating:

The original TP5 is still a great option for a very low powered and affordable solution, but consider looking at the TP5-PRO that has more processing power, a larger hard drive, and more memory available. The TP5 with it's built in printer is a nice space saving point of sale computer that provides a nice look for a retail setup. The screen is very responsive and looks quite nice with good color and contrast. The printer is slower then an external printer but that adds up to maybe half a second longer on a normal receipt.

Customer Reviews

Add a customer product review

Recommended Models

Ion TP5 14" POS Touch Computer, 1.8GHz, 2GB, 32GB SSD, Win10 IoT, Stand Alone Thermal Printer White USB (ION-TP5F-Z2T6, PG-WTPRINT)
$1,049.00
Ion TP5 14" POS Computer with Integrated Printer, 1.8GHz, 2GB, 32GB SSD, Win8.1 (End of life limited to stock on hand)
$1,064.00
  • operating system: Win Embedded 8.1
  • printer : Integrated 3" Thermal
  • printer : Integrated Printer
  • screen size: 14" W/S LCD PCAP
ION TP5 14" POS Terminal (Intel Atom 1.83 GHz with Integrated Printer, 2GB DDR3, 32GB SSD, Win10 IoT)
$1,064.00
  • operating system: Windows 10 IoT
  • printer : Integrated 3" Thermal
  • printer : Integrated Printer
  • screen size: 14" W/S LCD PCAP
ION TP5 14" POS Terminal (Intel Atom 1.83 GHz with Integrated Printer, 2GB DDR3, 32GB SSD, Win10 Pro x32)
$1,115.00
  • operating system: Windows 10 Pro
  • printer : Integrated Printer

Additional Models

POS Terminal (Intel Atom 1.83 GHz quad core, 2GB DDR3, 32GB SSD, Win 10 Pro x32) NO PRINTER
$965.51
  • operating system: Windows 10 Pro
  • printer : No Printer Included
Ion TP5 14" POS Touch Computer, 1.8GHz, 2GB, 32GB SSD, Win10 IoT, NO PRINTER
$938.00
  • operating system: Windows 10 IoT
  • printer : No Printer Included
Ion TP5 14" POS Touch Computer, 1.8GHz, 2GB, 32GB SSD, Win 8.1, NO PRINTER
$938.00
  • operating system: Win Embedded 8.1
  • printer : No
  • printer : No Printer Included
  • screen size: 14" W/S LCD PCAP
Ion TP5 14" POS Touch Computer, 1.8GHz, 2GB, 32GB SSD, No OS, NO PRINTER
$787.00
  • operating system: No OS
  • printer : No
  • printer : No Printer Included
  • screen size: 14" W/S LCD PCAP
Ion TP5 14" POS Computer with Integrated Printer, 1.8GHz, 2GB, 32GB SSD, No OS
$815.00
  • operating system: No OS
  • printer : Integrated Printer

Accessories

ION-MR514 ION Integrated MSR, 3-Track, ION TP5 14"
$84.00
Add to Cart
ION-TP5F-ZMOUNT TP5 Wall Mount Bracket, Bracket Only
$48.00
Add to Cart
ION-RD5-LCM TP5 2-Line Rear Display
$140.00
Add to Cart
ION-RD5-ZLCD8 TP5 8" Rear Customer Display
$280.00
Add to Cart
ZWE-TPC POS-X 2-Year Warranty Extension
$99.00
Add to Cart
ZOE-TPC3 3-Year Next Business Day Advance Exchange, POS Terminal
$121.00
Add to Cart
ZOE-TPC5 POS-X 5-Year Next Business Day Advance Exchange, POS Terminal
$255.00
Add to Cart
